Soundproof Perkins Diesel Generator Set Open Type With 3 Cylinders
- T/T L/C D/P D/A
- 7 days
You May Like
-
Soundproofing Portable Generator Perkins 16:1 Compression Ratio
-
Vertical In Line 6 Cylinder Diesel Generator With Four Stroke Cycle
-
Heavy Fuel Oil Perkins Diesel Generator Set Forced Water Cooling Cycle
-
Gensets Diesel Perkins Engine Three Phase 1500 Rpm 184kw / 230kva
-
1500 rpm Genset Perkins Diesel Generator Set Water Cooling Cycle
-
IP54 Silent Perkins Diesel Generator Set 1500rpm 220 KW 275 KVA
Product Details
| Brand Name | Perkins | Place of Origin | China | |
| Model Number | P137S |
Product Description
Certification:ISO9001/OEM
Soundproof Perkins Diesel Generator Set Open Type With 3 Cylinders
Powerful Generating Sets:
1. Diesel Generating sets from 5.2KVA to 2475KVA
2. All kinds of diesel generator are supplied ,from 10kva to 2000kva.
3. Engine brand for option:Cummins /Perkins /Deutz/Y Series/Smartslink Series/J (Kubota)etc.
4. Alternator brand for option:Stamford,Leroy Somer,Marathon alternator,etc.
5. Controller brand for option:Deepsea,Smartgen,ComAp,Harsen,etc.
6. Genset type:Open frame,Soundproof,trailer,etc.
7. Certificates:CE;ISO;OEM
Detailed Description:
| 1. Specification of genset | ||||||||||
| Gensets model | P137S | |||||||||
| Prime power (KW/KVA) | 108/137 | |||||||||
| Stand power?(KW/KVA) |
119/150.7 |
|||||||||
| Fuel Tank Capacity (L) | 180 | |||||||||
| Dimensions L*W*H | 2600*1100*1600 | |||||||||
| Weight(KG) | 1700 | |||||||||
| Rated Voltage | 380/220V | |||||||||
| Rated frequency(HZ) | 50 | |||||||||
| Rated Speed | 1500rpm | |||||||||
| Power Factor(COS￠) | 0.8(lagging) | |||||||||
| 2. Specification of diesel engine | ||||||||||
| Engine brand | Perkins | |||||||||
| Engine model | 1006TAG | |||||||||
| Number of Cylinders | 3 | |||||||||
| Cylinder arrangement | Vertical in-line | |||||||||
| Cycle | Four stroke | |||||||||
| Aspiration | Turbocharged, air-air after-cooled | |||||||||
| Bore×Stroke (mm×mm) | 100mm /127mm | |||||||||
| Displacement (Liters) | 6 | |||||||||
| Compression Ratio | 17.0:1 | |||||||||
| Speed Governor | Electronic | |||||||||
| Cooling System | Forced Water Cooling Cycle | |||||||||
| Total lubrication system Min.capacity (L) | 19 | |||||||||
| Fuel Consumption at 100% Load (L/h) | 29.9 | |||||||||
| Starting Method | DC24V electrical starting | |||||||||
| 3. Specification of alternator | ||||||||||
| Alternator brand | Leroy-Somer | |||||||||
| Alternator model | LSA44.3L10 | |||||||||
| Number of Phase | 3 | |||||||||
| Connecting Type | 3 Phase and 4 Wires | |||||||||
| Number of Bearing | 1 | |||||||||
| Protection Grade | IP23 | |||||||||
| Altitude | ≤1000m | |||||||||
| Exciter Type | Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire | |||||||||
| Insulation Class | H | |||||||||
| Telephone Influence Factor (TIF) | ≤50 | |||||||||
| THF | ≤2% | |||||||||
| Voltage Regulation, Steady State | ≤±1% | |||||||||
| Transient State Voltage | ≤-15%～+20% | |||||||||
Engine Main features:
1. Water-cooled, in-line diesel engine
2. Efficient fuel system for max power output and durability
3. Large-capacity air cleaner
4. Cost effective, fuel efficient and reliable performance
5. Functional engine with compact structure
6. Excellent after-sales service and sufficient spare parts supplying
7. Easy installation and ready access for routine maintenance
Engine design Characteristic:
1. Belt drive system:
? ? Belt drive system with tensioner offering automatic belt tension.
2. Maintenance:
? ? Wet liner capable for quick exchanging,cylinder head valve guide tube can
