Mini Size Plasma Cutting Machine

Place of Origin	China

Mini size plasma cutting machine ?YS plasma cutting machine could cut even,Website: , the shape of wave or other uneven shapes and steep pipe such cylindrical metal. ?Main Feature:Easy to use hand held controllerUnique design, easy to learn and operateBrushless micro stepper motors or servo motorPrecision Helical Rack-n-Pinion on X and Y axes with ballscrew on the Z axisPlasma table: Steel V-grid down draftWelded steel frame construction for rigidity and accuracyCuts up to 1" thick steel capacityHigh-speed cutting up to 800 IPMCompatible with standard G-Code filesMultiple torch options are available.Capacitance Height Control ??The adv ?anced height linear calibration technology makes the cutting nozzle and cutting board be within 3 ~ 30mm in the automatic height controlling in the capacitance mode; ?Simple and convenient linearization calibration ?The function of "One key for height calibration"guarantees that in any circumstances, the user only needs to press a key, he can calibrate the absolute height measurement and achieve a linear height measurement. ?YS THC control system able toPerform corner speed control and height control,Breakpoint restoration, automatic power-back recovery and automatic breakpoint memory,Special short line machining feature based on smooth travel, extensively applicable to metal blanking as well as advertisement and ironwork fabrication,Advanced material inclined discharging design. All finished work pieces and fragments slide into tunnel for safe and convenient collection.Working Area( XY): 1300*2500mm, 1500*3000mm or morePositioning Accuracy: 0.2mmRepeatability: +/- 0.3mm3 Axis Control Motor: AC Servo Motor or Stepper MotorController: Start Shaphon & Torch Height ControllerInterface: USBPlasma Power Supply: 63A, 100A, 120A, 200A,?300A?i.e.Table: Plasma tableTraverse System: Linear Guide on XY axis, Rack&Pinion on XYMax. Traverse Speed: 30m/minVoltage: 380V/ 3 phase; 220V/3 phaseCommand Language: G CodeOptional: ?1. American Cut-Master power supply (Power: 100A) together with high sensitive arc pressure adjuster is optional. ?2. Panasonic servo motor or Yaska servo motor is optional ?3. 200A plasma generator which can cut 2cm metal plate with smooth edge.?63A, 100A, 120A, 300A optional. ?4. MACH3 control system is optional. MACH3 MPG ?5. Oxygen fuel cutting system is optional. ?Start or starff control system. ?Whiich is most suitable for plasma cutting.?Huayuan brand plasma power,? Which have power ?63A, 100A, 120A, 200A,?300A?i.e. 200A plasma generator which can cut 2cm metal plate with smooth edge. Just choose the plasma power on your handling material thickness. Flame cutting functional ?The machine can with flame cutting function, with this function, the flame cutter can cut 0-150mm thickness steel. ?Table for working: ?There are two kind of table for your reference, one is have no structure, the rack is on the earth, another is the the working structure, if your machine axis X is more 1800mm, we recommend you’re the rack on earth type. Working sample:
