Double Twist Wire Netting Machine

Double Twist Wire Netting Machine

Quick Detail:

1.Gabion?making?Machine?is?the?professional?machine?to?produce?inerratic?gabion?mesh?,the?mesh?can?be?

used?to?produce?coop,?and?is?widely?used?as?protect?and??sustain?bank,?hillside,?road?and?bridge,?reservoir?

and?other?construction?project.

2.it?is?the?good?material?to?prevent?or?control?flood.

Descrition:

Gabion?making?Machine

The?LNWL?series?3?gabion?mesh?machine?can?produce?both?double?twisted?mesh?and?three?twisted?mesh?in?

the?same?gabion?mesh?machine,?it?is?very?economy.?A?set?of?gabion?making?machine?includes?four?main?

parts:?Mesh?weaving?machine,?roll?mesh?machine,?coiling?spring?machine,?warping?machine.

The?LNWL-3?series?gabion?mesh?machines?have?been?designed?to?make?gabion?mesh?of?various?widths?

and?mesh?sizes;?we?can?produce?the?machine?as?your?size.

Please?see?below?LNWL-3?gabion?making?machine?features:

·?LNWL-3?series?gabion?mesh?machines?use?RATCHET?BOX;?it?is?make?the?machine?weaving?mesh?

?more?easily.

·?LNWL-3?series?gabion?mesh?machine\'s?most?important?feature?is?that?it?can?weaving?both?three?

?twisted?mesh?and?five?twisted?mesh?in?the?same?machine.

Applications:

Gabion?making?Machine?is?the?professional?machine?to?produce?inerratic?gabion?mesh?,the?mesh?can?be?

used?to?produce?coop,?and?is?widely?used?as?protect?and??sustain?bank,?hillside,?road?and?bridge,?reservoir?

and?other?construction?project,?and?it?is?the?good?material?to?prevent?or?control?flood.
?

Specifications:

1.?Mesh?sizes:?60x80mm

2.?twist:?double?twist?&?three?twist

3.?Max.?netting?width:?4300mm

4.?Max.?galvanized?wire?diameter:?2.8mm

5.?Max?PVC?wire?diameter:?3.8mm

6.?Spindle?Speed:25r/min

7.?Power:?22Kw

8.?Size:?7200?x?1400?x?2400mm

9.?Weight:?15MT

10.?Theoretic?output:?165m/hr

11.?Automatic?stop?system?(option):?when?the?coiling?finished?or?wire?broken,?the?machine?will?stop?automatically

12.?Infrared?ray?safety?protection?system?(option)

13.?Automatic?oil?system

Competitive?Advantage:

1.?JINLIDA?company?invented?the?first?special?equipment?of?double?twisted?wire?netting?making?machine?in?

China?(patent?number:?ZL99229381.2?and?ZL00267066.5).?And?until?now,?we?have?persevered?in?this?area?

of?gabion?machine?making?for?15?years.

2.?All?the?parts?of?gabion?machine?are?processed?by?our?own?factory;?no?parts?were?send?to?outside?to?

process,?so?the?quality?can?be?ensured.

3.?We?can?provide?12months?guarantee?for?all?the?equipments,?and?if?customer?need,?we?will?arrange?our

?technician?to?help?install?the?machines?in?your?country,?and?also?could?supply?all?the?spare?parts?with?cost?

price?if?customer?need.
