TN2000C Spray and Baking Booth

Name:
TN2000C Spray and Baking Booth

Specification:
1. Out Size: (mm)  7000X5680X3450
2. Gate Size(mm)  3000(width)X2600(height)
3. Inner Size(mm)  6900X4000X2650
4. Total Power(Kw)  9.7

Room System of the Painting and Baking Room:
1. The structure of the room is bridge erection.
2. The wallboard is 50mm thick and is made up of polystyrene flame retardant colored and heat preservation materials.
3. The top of the room is made up of bend high quality galvanized armor plate.
4. The frame of the door use the specialized aluminium alloy materials. 5. The frame of the room is made up of high quality galvanized armor plate.
6. The floor is assembled by galvanized armor plate and anti-rotten aquare steel with two bars and three flower boards.

Blower System of the Painting and Baking Room:
1. two 3kw two-way centrifugal Fan with External Rotor, wind amount:22000m3h.
2. one 7.5Kw centrifugal fan with external rotor, wind amount:22000m3h. 3. The wind tank is made up of painting armor plate and aluminium alloy materials.
4. The vent-pipe is built by flange wich is made up of high quality galvanized armor plate and specialized equipments.
5. wind speed: 0.3 m/s
6. air exchange 260 time/h

Purified System of the Painting and Baking Room:
It can effectively catch the dust(>=10μm). The top highly effectively filter materials is Itallian imported filter cotton, which can effectively catch the dust(>=5μm). The floor filter cotton is fiberglass cotton.

Heating System of the Painting and Baking Room:
1. The burner is Italian liyalu G20. Its maximum heat value is 0.2 million Calorie.
2. The exchange uses SUS304 high quality stainless steel jointing. 10 newton imported from Swiss electronic executer can automaticly switch painting and baking.
3. Highest temperature: 80
4. Temperature-rising Speed 46min(2060); Oil Consumption46 Kg

Lighting System of the Painting and Baking Room:
1. Lighting in the top: 8x4(32)36w Philips lighting tube
2. Side Lighting: 6x2(12)36W Philips lighting tube
3. Illuminance: 900 Lux

Electronic Control System of the Painting and Baking Room:
1. The system uses electronic components which are produced by famous factories both at home and abroad.
2. The major loop has multi-protection and it can automatically display the whole work and fault status.
3. The system also has many functions such as temperature and time control, normal temperature painting, constant temperature painting, baking switch, lighting switch, stop switch, emergency stop switch, fault alarming, cumulative time.

Exhaust Gas Disposal of the Painting and Baking Room:
Direct exhaust and the environmental-protection tank is customized.
