Single Cage Rack / Pinion Industrial Lift , Building Lifter With 250m Lifting Height
- T/T L/C D/P D/A
- 7 days
You May Like
-
2 Ton Safety Industrial Lift Conveyor Machine for transporting Construction Materials
-
Industrial Rack and Pinion Hoist Construction Material Lift Equipment 500kg
-
Single Cage Industrial Material Hoist for 12- 24 Passenger or 750kg Heavy Materials
-
Single / Double Car Industrial Elevators
-
1 Ton Double Cage Industrial Lift High Safety and Flexible Carrying
-
Single Cage Industrial Lift For transport personnel , equipment and material
Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | CH-series |
Product Description
Certification:CE,ISO
Rack / Pinion Industrial Lifter Single Cage With 250m Lifting Height
?
?
Quick Detail:
?
|
Name |
Other Name |
Brand Name |
Control |
|
Industrial hoists |
Industrial hoists CH 2000/2000 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
2000kg/2000kg |
Certificate |
CE |
?
?
Description:
?
Industrial hoists CH 2000/2000 is installed and dismounted conveniently and can grow as high as the building grows height.The Industrial hoists has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment
?
?
Applications:?
?
CH serialization of products Industrial hoists is a Rack and Pinion EL. Industrial hoists widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.?
?
?
Specifications
Standard?technical datas of? double cars:
|
Parameter |
CH1000/1000 |
CH1600/1600 |
CH2000/2000 |
CH2700/2700 |
CH3200/3200 |
|
Rated |
1000/1000 |
1600/1600 |
2000/2000 |
2700/2700 |
3200/3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12/12 |
18/18 |
24/24 |
30/30 |
38/38 |
|
Max. lifting height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine power(kW) |
2*2*9.5 |
2*2*11 |
2*2*13 |
2*3*18.5 |
2*3*22 |
|
Car?inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Car?weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast?section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
?SAJ30-1.2 |
SAJ40-1.2 |
SAJ40-1.4 |
SAJ40-1.4? |
SAJ50-2.0? |
|
Hanger rated lifting capacity |
250 |
250 |
250 |
250 |
250 |
|
Rack module |
8 |
8 |
8 |
8 |
8 |
CH series?industrial hoists:?
1). Car load capacity: 1000kg~3200kg;
2). Lifting speed:33m/min, 0~40m/min;0~60m/min;
3). Increased lifting height on request;
4). Mast section: Painted or hot dipped zinc?
5). Car:double car?
6). Recommended car inner di
