Vertical Rack And Pinion Hoists
- 0 Kilogram / Kilograms per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Cradle Suspended Access Platform Equipment / Scaffold Ladders for Construction Site
-
Aluminum Alloy Working Suspended Access Platform with Steel Rope , Construction Scaffolding
-
Electric Rack And Pinion Hoists / Construction Elevator 3200kg High efficiency
-
Passenger and Material Hoisting Equipment Construction Elevator for Building Site
-
Rack and Pinion Man / Material hoist for Construction , Safety and High Reliability
-
Personnel and material Lifting Passenger Hoist / Electric Hoists 380V 50Hz
Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | CH-series |
Product Description
Certification:CE,ISO
?
Red 2700kg OEM Rack And Pinion Hoists for Building / Factory
?
?
Quick Detail:
?
|
Name |
Other Name |
Brand Name |
Control |
|
Rack and pinion hoists |
Rack and pinion hoists CH 2700 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
2700kg |
Certificate |
CE |
?
?
DeCription:
?
Rack and pinion hoists CH 2700 is installed and dismounted conveniently and can grow as high as the building grows height.The Rack and pinion hoists has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment
?
?
Applications:?
?
CH serialization of products Rack and pinion hoists is a Rack and Pinion EL. Rack and pinion hoists widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.?
?
?
Specifications
Standard?technical datas of?single car?:
|
Parameter |
CH1000 |
CH1600 |
CH2000 |
CH2700 |
CH3200 |
|
Rated |
1000 |
1600 |
2000 |
2700 |
3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12 |
18 |
24 |
30 |
38 |
|
Max. lifting height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine power(kW) |
2*9.5 |
2*11 |
2*13 |
3*18.5 |
3*22 |
|
Car?inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Car?weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast?section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
?SAJ30-1.2 |
SAJ40-1.2 |
SAJ40-1.4 |
