Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | CH-series |
Product Description
Certification:CE,ISO
Frequency Rack And Pinion Hoists CH 3200 Double Cars 3200kg Capacity
?
?
Quick Detail:
?
|
Name |
Other Name |
Brand Name |
Control |
|
Rack and pinion hoists |
Rack and pinion hoists CH 1600/1600 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
1600kg/1600kg |
Certificate |
CE |
?
?
?
Description:
?
Rack and pinion hoists CH 1600/1600 is installed and dismounted conveniently and can grow as high as the building grows height.The Rack and pinion hoists has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment
?
?
Applications:?
?
SC serialization of products Rack and pinion hoists is a Rack and Pinion EL. Rack and pinion hoists widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.?
?
?
Specifications
?
Standard?technical datas of? double cars:
|
Parameter |
CH1000/1000 |
CH1600/1600 |
CH2000/2000 |
CH2700/2700 |
CH3200/3200 |
|
Rated |
1000/1000 |
1600/1600 |
2000/2000 |
2700/2700 |
3200/3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12/12 |
18/18 |
24/24 |
30/30 |
38/38 |
|
Max. lifting height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine power(kW) |
2*2*9.5 |
2*2*11 |
2*2*13 |
2*3*18.5 |
2*3*22 |
|
Car?inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Car?weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast?section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
?SAJ30-1.2 |
SAJ40-1.2 |
SAJ40-1.4 |
SAJ40-1.4? |
SAJ50-2.0? |
|
Hanger rated lifting capacity |
250 |
250 |
250 |
250 |
250 |
|
Rack module |
8 |
8 |
8 |
8 |
