sh Fan Capacitor 2.5uf 3.5uf

Feature & Application
1.sh fan capacitor 2.5uf 3.5uf has small case, small dissipation factor, small inheterent temperature rise
2. High insulation resistance
3. Good self-healing characteristic
4. Very good pressure resistance function
5. CBB60 Motor Run Capacitor widely used as the start-up and running capacitor that is special for micro water pump, cleaning machine, washing machine and single-phase water pump motor.

Mounting parts (optional)
Threaded stud at bottom of can (M8, max.torque = 5 Nm)

Technical data and specifications

Reference standards: IEC 60252-1
Safety class according: IEC 60252-1 P0
Life expectancy to IEC 60252-1: 3,000(C) ~ 10,000h(B)
Rated capacitance CR: 1μF ~ 150μF (MFD)
Tolerance: ± 5%
Rated voltage VR: 110VAC ~ 630VAC
Rated frequency FR: 50/60Hz
Maximum permissible votage: Vmax 1.1 x VR (VR=Rated voltage)
Maximum permissible current: Imax 1.3 x IR (IR=Rated current)
AC test voltage terminal to terminal VTT: 2 x VR, 2s (routine test)
2 x VR, 60s (type test)
Dissipation factor: tan δ ≤0.002 (50Hz)
Climate types: 25/085/21 to IEC 60068-1
