Cross-Linked Polyethylene Pipe Molding Machine

Features of Cross-Linked Polyethylene Pipe Molding Machine:

The Cross-Linked Polyethylene Pipe Molding Machine is a newly developed pipe production line drawing on the most advanced overseas technology by our company.
As advanced production equipment of crosslinking polyethylene pipe, it utilizes one-step chemical crosslinking, which is one of the most advanced technologies, and simplifies production process. It enjoys low cost of pipe production, advanced and reasonable equipment structure and facile operation. The products are mostly applied in ground heating, conveyance system for potable water, industrial liquid, agricultural liquid and so on.
Structure Feature of Cross-Linked Polyethylene Pipe Molding Machine:
This unit is composed of forming and cooling fittings of stockpiling machine, pulling equipment, reeling equipment and other auxiliaries.
Major technical parameters of Cross-Linked Polyethylene Pipe Molding Machine:
Plunger chip diameter(mm): φ16.5
Plunger chip course (mm): 60
Punch frequency (times/mm): 250
Drive dynamo power (kw): 5.5
Drive dynamo rotate speed(r/min): 960
Heating power (kw): 9
Output (kg/h): 15-17
Machine weight (kg): 1000
Major technical parameters of auxiliary machine:
Maximum diameter of pipe (mm): ?32
Pulling speed (m-min): 0-2.5
Length printing method: Automatic
Printing method: Concave style
Maximum diameter of reeling pipe
Line reeling speed(m-min): 0-4
Pipe reeling and bundling length(m): 100
Machine weight(kg): 500
