RGBW LED ribbon driver 300watts , 4P phoenix for led pixel light / digital bar

RGBW LED ribbon driver 300watts , 4P phoenix for led pixel light / digital bar

RGBW LED ribbon driver, 4P phoenix connector output, CE Rosh certification
?
?
Quick Detail
Model Number: RT-DS300
Brand Name: RayElite
Type: led constant voltage controller
Lamp Power (W): 300w
Input Voltage (V): 90-250V
output: RGBW 4CH 24V/300W
Frequency: 1000KHz
Operating Temperature: 0~70℃
Gray Level: 256
?
Description:
The DS300 is ideal for controlling many types of constant voltage LED tape Including RGB, RGBW, RGBA and Multiple Single colour tape.It can be operated from a standard DMX controller (4Channel) or from Its stand alone built in programs Providing: Colour fade, Chase & Sound Triggered Chase with speed dim & sensitivity control. The SSL-DS 300 also has theability to dim its 4 outputs independently Allowing static colour and Dimming functions Multiple units can be connected togetherusing the master slave function
Easy connection, decoder supply signal and power together
High frequency output PWM, no flicker under camera
TVS protection, Isolation power
Decoder supply the power directly for easy connection
DMX addresses set manually by LCD display
Apply for led module, led pixel light, led digital strip, led digital bar etc.
DMX input : phoenix connector
Support RGB strip and single color strip and RGBW strip
Easy connect to DMX control systems
?
Applications:?
Disco and Club
Live performance
Stage show
architectural
Home decorate
?
?
Specifications :

?
Competitive advantages:
PWM Refresh-rate 1000HZ,suitable for TV studio,short circuit protection for avoiding reversed connection,high quality high efficency PSU
?
Detail & Effect
?
