CE Rosh 4 DMX channel 500MA CC led power supply smooth dimming curve for Stage show

CE Rosh 4 DMX channel 500MA CC led power supply smooth dimming curve for Stage show

4 DMX channel 500MA CC led power supply, smooth dimming curve, CE Rosh certification
?
?
?
Quick Detail
Model Number: RT-DL48-B
Brand Name: RayElite
Type: led constant current controller
Input Voltage (V): 90-250V

output: RGBW 4CH, 48V/500MA

Data Input: DMX512
Place of Origin: Guangdong China
Gross Weight: 1.6kg
Package Size: 194*135*70mm

?
?
?
Description?
LED fixture offers unlimited colors to enhance your enviroment. The versativity natures and reliable performance of this product makes it ideal for all sectors of entertainment.?
?
?
?
Specifications :

?
?
Menu?MAP
?

?
?
DMX MODE

In DMX mode, you have 5 modes to select according to programming requirement for your environment: 4ch, 5ch, 6ch, 7ch and 8ch mode.
?
?
TEST?MODE
?
Test Mode is designed to test LEDs and fans if they are all working. 1. Press MENU botton to scroll top menu until Test Mode displays, press Enter button to enter Test Mode. 2. Use Up/Down button to select Test LED or Test Fan, then press Enter button to go to Test LED or Test Fan. 3. Press Up/Down to test Red, Green, Blue, All LEDs or test fan ON/OFF
?
?
?
SLAVE?MODE
In Master/Slave operating mode, all Slave units are to be set to Slave Mode and Slave ID is required for each Slave unit. 1. Press MENU button go to System Mode, then use Up/Down button to select System Mode [Slave] and press Enter button to enter. 2. Use Up/Down button to set up a Slave ID number for that unit. The first Slave connected with the Master unnit is Slave ID [1], the next Slave units are Slave ID [2], Slave ID [3], and son on.?
?
?
AUTO?MODE
In this mode, you can combine 3 editable, 21 built-in programs and running time of each program without external DMX controller?
?
?
Applications:?

Disco and Club

Live performance

Stage show

architectural

Home decorate?

?
?
Competitive advantages:
wall mount, high quality high efficency PFC power supply with CE RoSH SAA C-tick approval from meanwell, refresh rate 1000HZ for TV studio stage venue, free flickering,RGBW 4ch mixer, 2x16 LCD display,new firmware updatable via DMX port.
?
?
?
Detail & Effect
