Sell 5-Gallon Bottle Blow Molding Machine

Place of Origin	China

Model No.:JS-2II
Product Origin:China
Brand Name:JS
Price Terms:FOB Ningbo or FOB Shanghai
Payment Terms:T/T or L/C
Certification:CE
Description:JS-20II semiautomatic bottle blow molding machine (for 3-5gallon): 1) Especially used to produce 3-gallon and 5-gallon bottles and any shape of plastic from PET 2) Perfect function with economic investment 3) Small size and compact construction with no space waste 4) Easy to operate and maintain, operation by one person 5) Saving power and uneasy to worn out 6) Adopting new double crank four bars to lock mould, the cross fixed 7) Providing high pressure blowing system 8) We can provide performs and various bottle and cap molds for 5-gallon and 3-gallon bottles to meet customer's requirements Main parameters: 1. Mold gathering strength (kN): 150 2. Mold traveling distance (mm): 400 3. Pulling rising traveling distance (mm): 550 4. Mold hole number (cavity): 1 Bottle specifications: 1. Max. bottle capacity (L): 20 2. Max. tooth part size (mm): 60 3. Max. bottle diameter (mm): 300 4. Max. bottle body height (mm): 550 5. Theoretic production capacity (bph): 60-90 Electric power specifications: 1. Total power consumption (kW): 11.5 2. Thermal rating (kW): 10.4 Air pressure specifications: 1. Operating pressure (kg/cm2): 8 2. Low pressure gas consumption (L/min): 250 3. Bottle blowing pressure (kg/cm2): 30 4. High-pressured gas consumption (L/min): 400 Machine: 1. Machine size (m): 2.8 x 0.7 x 2 2. Machine weight (MT): 2
