Two-axis CNC Heavy Duty Gear Chamfering Machine Vertical YH9332F

Two-axis CNC Heavy Duty Gear Chamfering Machine Vertical YH9332F

Description:

YH9332F is vertical layout two-axis CNC machine, which adopts interval indexing,continuous process theory. The machine adopts two end edge chamfering cutters to machining end face point angle,crown angle, in addition also can use one special chamfering cutter to machining heavy-duty internal gear of end surface round angle.

The machine have following features: two CNC axes are workpiece spindle and workpiece feed spindle, the workpiece rotation adopts servo motor to drive high-precision,dual-lead indexing worm gear. The feed motion adopts servo motor to drive ball screw pair. The cutter support is vertical layout with two cutter spindle structure, the motor is direct connected, and the speed of cutter spindle adopts frequency
conversion stepless speed adjustment. The machine high efficiency, stable performance,adjustment is easy; applicability range is wide,good quality characteristics.

Parameter table:

Company Profile:

Heng Yong company gathered many experienced experts. This team is lead by people have over decades of experience, and filled with young, energetic engineers. With strong research and developing ability, our company put extraordinary effort on developing complete sets of gear machinery. Now we are able to provide our customer the main products as follows: Gear Shapers, Straight Bevel Gear Generators, Spiral Bevel Gear Generators, Spiral Bevel Gear Grinders, Hypoid Gear Testers, Gear Lappers, Gear Quenching Press, Gear Chamfering Machines, Gear Hobbers, Honing Machines, Vertical & Horizontal Machining Centers, Special Precision Speed Reducers, Roll Stander for Seamless Tube Stretch Reducing Mill, Gear Coupling Family, Low Drive Devices and Environmental Protective Equipment of 16 kinds, more than 30 families, and more than 150 types and specifications. The company focus on developing heavy-duty, large CNC gear machinery, which are urgently needed by the government and makes industrialize as soon as possible, provide a great variety of advanced gear machinery to the market. The company is using the leading 3D designing software for developing and designing. The company combines producing with research and development by Cooperating with TIANJIN University and other colleges for many years.
