ATV Winch
Negotiable
/ Set
1 Set(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Place of Origin | China |
Product Description
Certified as CE and FCC, this P3500-1D ATV Winch is specially designed with different planetary gearing for heavy duty. Widely used in vehicles and boats, this ATV Winch, as a power tool, is able to recover itself in the snow ground, marsh, desert, sea beach, muddy mountain road and in other kinds of bad environment. To learn more about this P3500-1D ATV Winch, please click the left side picture and see the features and specifications as below.
- Features:
- Free Spooling Clutch
- Automatic Braking Action
- Specially designed with different planetary gearing for heavy duty
- Solenoid Control Box supplied
- Specifications:
- Rated line pull: 3500 lbs (1588 kgs) single line
- Motor: Permanent magnet, 0.8kw/1.1hp 12V
- Gear reduction ratio: 128.2:1
- Geartarain: 3-Stage Planetary
- Clutch (free spooling): cam activated
- Cable (Dia x L): (Dia.)3/16”X50”((Dia.)5.4mmX15mm)
- Drum size (Dia x L): (Dia.)1.77“X3.19“((Dia.)45mmX81mm)
- Overall dimensions (L x W x H): 13.6“X4.6“X4.8“(345mmX118mmX121mm)
- Packing size: 38X31X31cm 2PCS/CTN
- Weight: N.W/G.W:25kg/27kg
- Notice:
- Do not use winch as a hoist
- Do not use for transportation of people
- Do not operate and spool under full load over one minute continuously
- While motor is overheating, please stop it for a while to cool it down
- Limited warranty
