Sell Protocol Converter

Place of Origin	China

Model No.:OM2101-E1/V.35
Product Origin:China
Brand Name:
Price Terms:EXW, FOB Shenzhen / Hong Kong
Payment Terms:T/T
Certification:CE, ISO9000
Description:Specification: The OM2100 series desktop Protocol Converter can exchange between 1~4 E1-Ethernet, E1-V.35, V.35-Ethernet etc. For convenient management, OM 2100 can also provide build-in concentrating supervision and control. ASIC is the core of the design of OM2100 series protocol converters. With special technologies such as VR Technology, Digital Lock Phase and Clock Extraction Technology and 2M connect with Anti-interference, the software in the equipment is designed with modulation including encode, decode, information insertion, alarm transferring, thus it simplifies the circuit and promotes the reliability of the whole cabinet. OM2100 series protocol converter uses communication circuit E1, providing the broadest band 2M channel for data transmission, connecting two LANs by transmission equipments such as optical transceiver. It can be applied to various occasions such as LAN extension, Network isolation, and LAN access to WAN etc. and can also connect Ethernet to telecommunication transmission network, private network or LAN through channel E1. Key Features: Port E1 can provide both 120ohm RJ45 and 75ohm OMNC Support analog loopback, digital loopback and remote loopback under Framing Support inter clock, external clock and line clock(slave clock) Ethernet provides 2 kinds of connectors: straight-through and crossover cable order Ethernet ports provide optical and electronic ports Parts of Ethernet have the function of MAC address filtration, studying and aging. Can supervise the status of remote terminal through PHP network management of central office terminal equipment Can auto-supervise channel E1 and choose the feasible channel E1 from the 4 channels (applicable to OM2104-E1TX) Desktop in design, also supporting hanging Cabinet type can be installed in 19" standard rack With unitive network management platform, provide network management including user desktop equipment and central office rack-mount type; 220V AC and -48V DC are available. OM2100 Desktop Type OM2101-FE1TX Conversion from 1 FE1 to Ethernet port OM2101-E1TX Conversion from 1 E1 to Ethernet port OM2101-V35E1 Conversion from 1V35 to Ethernet port (FE1 and E1 are adjustable) OM2101-V35TX conversion from 1V35 to Ethernet port OM2104-E1TX Conversion from 1 to 4 E1 to Ethernet port OM2108-E1TX Conversion from 1to 8 E1 to Ethernet port OM2101-E1FX-MM Conversion from 1 E1 to Ethernet MM optical port OM2101-E1FX-SM Conversion from 1 E1 to Ethernet SM optical port OM2101-FE1FX-MM Conversion from FE1 to Ethernet MM optical port OM2101-FE1FX-SM Conversion from FE1 to Ethernet SM optical port OM2101-V35FX-MM Conversion from 1 V35 to Ethernet MM optical port OM2101-V35FX-SM Conversion from V35 to Ethernet SM optical port OM2104-E1FX-MM Conversion from 4E1 to Ethernet MM optical port OM2104-E1FX-SM Conversion from 4E1 to Ethernet SM optical port OM2106-1TX4E1-SM20 Multi-functional diplex converter, one 1000BASE-T, 1RS232 and 4 E1 to 20km SM optical connector OM2101-V35OM-SM V35 optical connector converter (cat), SM, 20km OM2101-E1OM-SM 1 optical connector converter (CAT), SM, 20km OM2101-E1TX8V-S Diplex conversion from E1 data to voice, 1 1000 Base-T,8 voice simulating port, user (connecting to phone) OM2101-E1TX8V-O iplex conversion from E1 data to voice, 1 1000 Base-T,8 voice simulating port, central office terminal (connecting to telephone exchanger) Packing: OLYCOM brand or Standard
