ring die pellet mill

FOB Price

Negotiable / Set

1 Set(Min.Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	YULONG		Place of Origin	China
Model Number	HKJ Series

Product Description

ring die pellet mill/ granulator/ pelletizer description:

This kind of ring die pellet mill is widely used for making animal feed for such as fish,chickens,ducks,rabbits,pigs ,horses,cattle and other kinds of animal and poultry.The products are small pellets or granules with the diameter 1.5-12mm.

1.On the basis of absorbing advanced technologies domestically and abroad, the machine group has adopted mosaic rotating roller. During working process, the press roller can be adjusted at will. And all functions have reached advanced world standard.

2.The machine has forced material-entrance and overload protection device, which makes it work much safer.

3. Modulator with large diameter has been used in this machine to make materials fully cured, and make the pellet smoother. The formation rate reaches 98% and the equipment wear rate has been fallen to the bottom.

4. Speed-adjust feeding, adopted by this machine, can control the feeding capacity correctly to fit for different materials and meet the production requirement of pellets with different diameters.

Technical Parameter:

Parameter	HKJ 250	HKJ 300	HKJ 350	HKJ 450	HKJ 610
Capacityt/h	0.5-1.5	1-3	3-5	4-7	7-11
Power of main motorkw	22	45	55	90	150
Power of feederkw	1.5	2.2	2.2	3	3
Power of conditionerkw	1.1	1.1	1.1	1.5	2.2
Inner diameter of diemm	Φ250	Φ300	Φ350	Φ450	Φ610
Rotate speed of dier/m	348	348	348	348	348
Quantity of rollers	2	2	2	2	2
Rotate speed of feeder/min	12-120
Rotate speed of conditionerr/min	350
Pellet specmm	Φ1.5 Φ2Φ2.5Φ3Φ3.5Φ4Φ4.5 Φ5Φ6Φ8Φ10Φ12
Pressure of steammpa	0.1-0.4
Steam usingt/h	≥0.3
Temperature of steam	130-150
