Three Way Ball Valve

Product Sort: Ball Valve->3 Way Ball Valve
Product Material: Cast steel:A216WCB, A217WC6, A217WC9, A351CF8, A351CF8M, A351CF3, A351CF3M, A352 LCB, A352LCC ,Forged Steel : A105, A182 Gr.F304, A182 Gr.F316, A182 Gr.F304L, A182 Gr.F316L,A182 Gr.F11, A182 Gr.F22,A350 Gr.LF2, F51

Specification Standard & Major Parameter

1.Product Enfored Standard:
Design & Manufacture Std.:API 608,API 6D,ASME B16.34,BS5351
Face to Face Std.: ASME B16.10, API 6D,DIN 3202
End Connection Std.: ASME B16.5, ASME B16.47,DIN2543-2550
Test Standard: ,API 6D,API598,BS 6755,ISO5208,MSS SP-82,MSS SP-61
Fire safe: API607-API6 Fa

2. Major Parameter:
Size: 2-56
Pressure: 150LB-2500LB
Material: Cast steel:A216WCB, A217WC6, A217WC9, A351CF8, A351CF8M, A351CF3, A351CF3M, A352 LCB, A352LCC ,Forged Steel : A105, A182 Gr.F304, A182 Gr.F316, A182 Gr.F304L, A182 Gr.F316L,A182 Gr.F11, A182 Gr.F22,A350 Gr.LF2, F51
Structure Type: 2-pc;3-pc, floating ball,fixed ball, Reduced Bore,Full Bore
Operated Way: Lever, Hand wheel, Gear, Pneumatic or Electric

3. 3 Way Ball Valve Design Feature,

Blow-out proof stem, Anti-static Device, Fire Safe Seat Sealing, Low Emission Control

We could produce Cast Steel 3 Way Ball Valve and Forged Steel 3 Way Ball Valve which are all according to the customers requests,including design and material. Also we could choose the best ball valve for our customers,which is the most suitable for the working environment.
