Home > Products > Impact Extrusion Press > Vertical Hydraulic Impact Extrusion Press for Aluminum Iron and Zinc Can/Bottle Production
Vertical Hydraulic Impact Extrusion Press for Aluminum Iron and Zinc Can/Bottle Production
- T/T L/C D/P D/A
- 7 days
You May Like
-
Tripple Headed Automatic CNC Wood Routers Wood Door And Window Cutting And Processing
-
Automatic Water Cooling CNC Wood Routers Wood Working - piece Processing Wood Cutting
-
Convenient Portable EDM Cutting Machine For Broken Bolts Drill Taps and Studs
-
Portable Light Weighted EDM Cutting Machine For Broken Bolts Taps
-
Horizontal Cold Extrusion Press Machine For Extinguisher / Zinc Tube
-
Horizontal Cold Impact Extrusion Machine For Aluminum Cans / Bottles
Product Details
| Brand Name | WKH | Place of Origin | China | |
| Model Number | N/A |
Product Description
Certification:ISO9001:2000
Quick Detail:
Extrusion press used for collapsible tube and can producing. Materials of Aluminum, iron and Zinc are all suitable for producing with impact extrusion press, and products include cans, bottles, capacitor shell, battery case, etc. Extrusion press can be categorized into Horizontal extrusion & Vertical extrusion; mechanic extrusion & hydraulic extrusion. We have rich experiences in the can production, we know well about each type of the extrusion press and we are able to provide whole solution to you.
Applications:
Used for production of collapsible tube, cans, bottles with the materials of aluminum, Iron and zinc. For example, aluminum cans for capacitor shell, aluminum shells for automobile filters, aluminum cans for extinguisher, zinc tube for battery case. Extrusion press is widely applied in the industries of electric, automobile, cosmetics, meter, aviation, military etc.
Specification of Horizontal extrusion press:
|
Item |
Unit |
60A |
60B |
180 |
200B |
200C |
200K |
|
Nominal pressure |
KN |
600 |
600 |
1800 |
2000 |
2000 |
2000 |
|
Nominal pressure stroke |
mm |
5 |
5 |
5 |
5 |
5 |
5 |
|
Stroke of slide |
mm |
220 |
145 |
250 |
300 |
190 |
155 |
|
Stroke per minute |
Min-1 |
60 |
100 |
65 |
65 |
85 |
100 |
|
Max shut height |
mm |
355 |
355 |
460 |
480 |
480 |
480 |
|
Adjustment of shut height |
mm |
5 |
5 |
12 |
12 |
12 |
12 |
|
Max diameter of can |
mm |
Φ25 |
Φ20 |
Φ48 |
Φ55 |
Φ50 |
Φ45 |
|
Max length of can |
mm |
130 |
90 |
170 |
200 |
110 |
100 |
|
Power of main motor |
KW |
5.5 |
5.5 |
11 |
11 |
11 |
11 |
|
Item |
Unit |
265 |
315A |
315B |
|
Nominal pressure |
KN |
2650 |
3150 |
3150 |
|
Nominal pressure stroke |
mm |
8 |
10 |
10 |
|
Stroke of slide |
mm |
342 |
385 |
270 |
|
Stroke per minute |
Min-1 |
58 |
