Product Details
Brand Name | DONGZI | Place of Origin | China | |
Model Number | KL32-0.5-80 |
Product Description
Certification:CE SFDA
Digital Medical X-ray Tubes , X ray machine tube For Bone Mineral Densitometer X-ray System
Quick Detail:
Type:Station anode x-ray tube
Application: For Bone Mineral Densitometer x-ray system unit.
Model: KL32-0.5-80
Equivalent to BRAND X-RAY BX-1
Integrated high quality glass tube
Description:
KL32-0.5-80 Stationary X-Ray Tube is especially designated for bone densimeter x-ray system and available for nominal tube voltage constant potential circuit
KL32-0.5-80 tube has one focus.
The integrated high quality tube with glass design has one super imposed focal spot and a
reinforced anode. The high anode heat storage capacity ensures a wide range of applications for bone densimeter x-ray application. A special designed anode enables an elevated heat dissipation rate which leads to a higher patient throughput and a longer product life. A constant high dose yield during the entire tube life is ensured by the high density tungsten target. Ease of integration into system products is facilitated by extensive technical support.
Applications:
KL32-0.5-80 Stationary X-Ray Tube is especially designated for bone densimeter x-ray system and available for nominal tube voltage constant potential circuit
Specifications:
Nominal Tube Voltage(self-rectified)……..………………..….………..…….……………95kV
(constant potential)………………..….………..…….……………80kV
Nominal Tube Current .……………………………..….……….…………………………...2mA
Nominal Operating Condition………………………….…….....................80kV@2mA@2.4V
Nominal Anode Cooling Rate………………………………………………………………160W
Anode Heat storage Capacity ………………………………………………………………16kJ
Filament current………………………………………………………….…1.95 A@2.4V±0.2V
Focal spot ………………………………………………………………….0.5 (IEC60336/2005)
Target Angle……………………………………………………………….………………..…12°
Effective X-ray Cone Beam…………………………………………………………..24°X90°
Target Material………………………………………………………………….………..Tungsten
Cathode type……………………….………………………………………….Tungsten filament
Dimensions ……………………………………………..…..125mm length by 35mm diameter
Weight………………………………………………………………………….approx.145 grams
Competitive Advantage:
Elevated anode heat storage capacity and cooling
Constant high dose yield
Excellent lifetime
