Home > Products > PP Woven Bag making Machine > 10kw Automatic Super Thin Blown Film Making Machine With Moment Motor
10kw Automatic Super Thin Blown Film Making Machine With Moment Motor
- T/T L/C D/P D/A
- 7 days
You May Like
-
380v Knitting Plastic Woven Bag Printing Machine 1500-3500pcs/Hour
-
6kw PP Woven Bag Making Machine Plastic Woven Bag Cutting And Sewing Machines
-
Exquisite High Speed Label Slitting And Rewinding Machine 70m/Min
-
Full Automatic Adhesive Tape Rotary Label Die Cutting Machine CE
-
Automatic Flexo / Graphic Label Printing Machines 60m/Min 380V
-
Plastic Film High Speed Solventless Lamination Machine 300m/Min
Product Details
Brand Name | HERO | Place of Origin | China | |
Model Number | CM450/600/800/1000 |
Product Description
Certification:CE
Quick Detail:
CE Certificate 380V? 50Hz HERO BRAND extrusion system Two screw automatic precise temperature controller moment motor PP filmDescription:
The Line applies extrusion system made of special steel, high precision die head,(optional reversing die head) automatic precise temperature controller, contact-free solid-state relay and other famous national brand electronic parts.
The machine applies speed adjustment of frequency conversing to stabilize the running and increase the productivity with low energy and good reliability
With moment motor, the tension of the winder works evenly so as to produce flat films with good appearance
The machine is applicable for the raw material of PP to constantly blow films with varees specifications
Specifications:
model | cm450 | cm600 | cm800 | cm1000 |
applicable material | PP | PP | PP | PP |
film worth | 400mm | 600mm | 800mm | 1000mm |
film thickness | 1.5c-6c | 1.5c-6c | 2c-8c | 2c-8c |
screw diameter | 45mm | 50mm | 55mm | 65mm |
L/D ratio | 30:1 | 30:1 | 30:1 | 30:1 |
die head diameter | 120mm | 180mm | 220mm | 280mm |
heating power | 7.5kw | 10kw | 15kw | 20kw |
master motor power | 7.5kw | 11kw | 15kw | 18.5kw |
output | 25kg/h | 40kg/h | 50kg/h | 60kg/h |
halloff motor length | 520mm | 680mm | 880mm | 1050mm |
halloff motor power | 0.75kw | 0.75kw | 1.5kw | 2.2kw |
halloff speed | 10-60m/min | 10-60m/min | 10-60m/min | 10-60m/min |
winding motor power | 30kg | 40kg | 40kg | 50kg |
winding diameter | 650mm | 650mm | 650mm | 600mm |
machine size | 4.2*1*3 m | 4.2*1.2*3.6 m | 4.4*1.6*3.8 m | 6*2.2*5 m |
weight | 1.8 t | 2.1 t | 2.4 t |
3.3 t ? |
About Us :
HERO PLASTIC PLASTIC MACHINE CO.,LTD SINCE 1985 found at the ground south along the sea (Namely China packing City ), is a two more than ten years,enterprise specializing in making complete set of series soft packing equipments.Now the company collect an elitist for been gaged inning the design,manufacturing,examining,debugging,The whole staff of enterprise \"Striving for Survival by Quality, Striving for Development by Creative\" encourage bottom,under the concern and support of the commerce colleague,pass by not the gradually become to have to completely design to develop the ability, forerunner the production the craft with the stubborn at full split,complete process the equipments,strict examination means,science the factory hoist that manage.
Facing the new century shangwang person with the acute market competition,and fix attention on the future and have a foothold creative,constants identical.Insist\"Quality Frist,Customer Supreme\"for operate the aim.With the machine product of the high quality,on time the thoughtful service create to set up the good brand,then repay the large customer to support shangwang print machine.Our product is distributed all over the country,and exported to southeast Asia,Middle-east,Russia,South America,Africa,and the product was charmed the client.
