2 Segments Hot Dip galvanised steel pole Slip Joint 100% compelete Penetration

FOB Price

Negotiable / Set

1 Set(Min.Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	BOSHENG		Place of Origin	China
Model Number	BS/PT - 13

Product Description

Delivery Time:15 - 25 work days
Certification:ISO9001:2008
2 Segments Hot Dip Galvanized Transmission Line Steel Power Pole

?
Specification?
?
?

Steel	Yield Strength(MPa)	standard	Standard Title	Metallic element	Content	?
main ingredient Q345	345 for Thickness<=16	GB/T 1591-2008 (ASTM A572/A572M-15 ,EN10025 S355N)	High strength low alloy structural steels	C	≤0.20	?
				Mn	≤1.70	?
				Si	≤0.50	?
Accessories Q235	235	GB/T 700-2006 (ASTM A283 Gr.B ,EN10025 S235JR)	Carbon structural steels			?
				P	≤0.035	?
				S	≤0.035	?

Welding	Standard	Standard Title
Pole shafts&multi-sided tubular Cross arms&all accessories	AWS D1.1/D1.1M:2010	Structural Welding Code-Steel
Welding wire	AWS D1.1/D1.1M:2010	Structural Welding Code-Steel

Hot dip galvanizing	Standard	Steel thickness/mm	Mean coating thickness/μm	Metallic element	Content
Pole shafts,cross arms&bolted on accessories	ASTM A123/A123M-15 AS/NZS 4680	>6	85	Mn	0.25%-0.40%
		<3-6	70	Mn	0.25%-0.40%
		1.5-3	55	Cu	<0.15%
		<1.5	55	Cu	<0.15%
Bolts,nuts&washers	GB/T 5267.3-2008 (ISO 10684-2004)	_____	≥ 54	P	<0.025%
Foundation bolts	ASTM A153/A153M-09	_____	≥ 54	S	<0.03%

Description?
?
Through the efforts of the company staff, the support and cooperation from all over the world. The company's products have been exported to Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc. We have good export experience and with 1 container export to World in average every day.

Our steel poles, being manufactured from steel sheet that has been subjected to hydraulic pression and longitudinal welding, has a tapered tubular structure with a multilateral cross section. To achieve a proper height, steel poles can be assembled by insert mode or flange mode at the installation site.

The hot dip galvanization technique could protect steel pole from corrosion for as long as 50 years

As an alternative to the traditional wood and concrete poles, our hot dip galvanized steel pole could be utilize to bear the conductors and electric distribution equipment, power transmission equipment, cables, etc.

But to design the practical poles for customers use, normally we need customer to provide us some parameter, like as following :
?
?
- Pole top design load
- Where is the position of the load , the distance from the top
- The wind Speed
- How will the wire distribute
- Pole type with Burial Type or Base Plate type
- The connections mode , use slip joint or flange
- and others we can further more discuss when we need.
?
?
Accessories:
?
1. Pole
2. Base Plate
3. Pole Top Cap
4. Butt Bearing Plate
5. Holes
6. CrossArm
7. Grounding Nut & Bolts
8. Anchor Bolts
9. Climbing Rungs
10. Identification Plate
11. Bituminous Painting if needed
12. Hot dip galvanized.
?
?
Production Line
?
The fabrication process as cutting plate, bending/forming, automatic welding, drill holes, quality check before galvanized, hot dip galvanized , recalibration, inspect according to client’s required then delivery on time as Constract
?

Our Services
?
1. Reply your inquiry in 24 working hours.
?
2. Experienced staffs answer all your questions in fluent English.
?
3. Customized design is available. UEM & UBM are welcomed.
?
4. Exclusive and unique solution
