Home > Products > New product > High Power Vertical Ripple Reistor
High Power Vertical Ripple Reistor
Negotiable
/ Piece
5000 Pieces(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | KHX | Place of Origin | China | |
| Model Number | High Power Vertical Ripple |
Product Description
- Two terminal extensions are fixed on both ends of a ceramic tube on whose surface winds wave-shaped alloy resistance wire and a high temperature-resistant and fireproof coating are applied. The ceramic tube can function as resistance wire skeleton and heat radiator as well . This product can be customized to special needs of customers and applicable to simulation load test, equipend discharge, automated control and inverters energy loss brake.
II.Technical Data
- Rated Power Range: 50W-2500W
- Voltage Range: 0.5KV10KV
- Resistance Range: 1R-1KR
- Dielectric Voltage: AC2.5KV-20KV/1min 50Hz
- IP Class: IP00
- Vibration: 1g
- Rated Temperature Rise: 375
- Temperature Coefficient: 80-400ppm/
- Carrier Material: 0Cr25AL5/Ni80Cr20 Optional
- Advantage: Work in high voltage
- Disadvantage: Inferior vibration
