Waterproof Outdoor Telecom Cabinets , Outdoor Equipment Cabinet With Air Conditioner
Negotiable
/ Piece
1 Piece(Min.Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Galvanized Steel Thermostatic Outdoor Telecom Cabinet , Outdoor Electronics Cabinet
-
Cooling Fans Air Conditioner Thermostatic BTS Outdoor Cabinet 3 Bays ISO9001 CE Certification
-
3 Compartments Outdoor Integrated Base Station Cabinet For Installation Equipment And Battery
-
LED Lamp Pole Mounted Outdoor Battery Cabinet , Outdoor Communication Cabinets With Door Sensor
-
435460736 mm Outdoor Pole Mount Enclosure For Telecom Base Station
-
Battery Compartment Outdoor Wall Mount Cabinet With Auxiliary Direct Ventilation Fans
Product Details
| Brand Name | ESTEL | Place of Origin | China | |
| Model Number | DDTE082 |
Product Description
Certification:ISO9001, CE, 3C, FCC, TLC, IP55
Waterproof Outdoor Telecom Cabinets , Outdoor Equipment Cabinet With Air Conditioner
Quick Details:
| Place of Origin: Shenzhen, China (Mainland) | External Size H×W×D 2195×900×900mm |
|
Brand Name: ESTEL |
Structure: sandwich structure, double wall, with insulation |
|
Model Number: DDTE082 |
Cabinet Layout: one compartment, for installing 19” equipment |
|
Product Name: Outdoor Telecom Equipment Cabinet |
Cabinet Lock: anti-theft three point lock |
| Certification: ISO9001, CE, 3C, FCC, TLC, IP55 |
Protection Level: IP55 |
| Application: outdoor telecom base station | Cable Entry: at cabinet bottom |
| Material: galvanized steel (support custom made) | Illumination: DC48V LED lamp |
|
Heat Insulation: PEF |
Grounding Protection: copper bar |
|
Color: grey (support custom made) |
Cooling: AC220V Air Conditioner and DC48V Fans |
|
Coating: anti-corrosion outdoor powder coating |
Accessories Options: PDU, temperature control switch |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Payment Terms: | L/C,D/A,T/T, Western Union, Paypal, etc |
| Supply Ability: | 6,000 sets per month |
| Delivery Time: | 15-20 working days |
| Packaging Details: | wooden case |
1. Specifications
(1) Technical Parameters
| Item | Type | Technical Parameter |
| Structure | Dimension |
External Dimension: H×W×D 2195×900×900mm |
| Layout | 1 compartment | |
| Equipment Installation Method | 19” rack | |
| Door | With one front door, and anti-theft three point lock for outdoor cabinet (support padlock) | |
| Material | Galvanized steel ; 1.5mm thick outer plate, 0.8mm thick inner plate | |
| Heat Insulation | There are heat insulation between inner wall and outer wall. The insulation material is 20mm PEF. | |
| Structure | Assembled | |
| Ingress Protection | IP55 | |
| Temperature Control | Cooling | AC220V air conditioner and DC48V fans |
| Lightning Proof | Grade B lightning proof | Nominal: 60KA, Max.: 100KA |
| Lighting | LED lamp | 48V LED lamps (immovable), with protective circuit breaker |
| Temperature | Temperature | Working Temperature: -40°C ~ +55°C |
| ? | ? | Storage Temperature: -50°C ~ + 70°C |
| ? | ? | Transport Temperature: -50°C ~ +70°C |
| Humidity | Relative Humidity | 5% ~ 100% |
| Pressure | Air Pressure | 62kpa ~ 101kpa (similar to 0m ~ 5000m altitude) |
| Radiation Intensity | Solar Radiation Intensity | 1120 ×(1±5%)W/m2 |
(2) Accessories List
