260W Anti - Aging Photovoltaic Solar Module Solar Energy Panels For Homes

Brand Name	ZOCEN		Place of Origin	China
Model Number	ZCM6-60P

Delivery Time:5-10 days
Certification:CE, CQC, IEC, TUV, CEC, MCS, CHUBB, BV, ISO9001

260W Anti - Aging Photovoltaic Solar Module Solar Energy Panels For Homes

Materials	156*156mm Monocrystalline solar cells	Max.power	260W
Positive tolerance	0~3%	Size	1640*992*40mm
Solar panel efficiency	15.98%	Type	Mono
Bypass Diodes	6pcs 12A	Warranty	25 years
Producion Capacity	200MW / year	Color	Deep blue

260W Monocrystalline Solar Panels With Bsf Improved Cell Conversion Efficiency

1> Quick Detail:

Place of Origin: China Brand Name: ZOCEN Model: ZCM6-60P Certificate: CE, CQC, IEC, TUV, CEC, MCS, CHUBB, BV, ISO9001

2> Description:

Product name: 260W Monocrystalline solar panels / modules / photovoltaic solar panels / PV solar panels Solar cell: 156*156mm(6 inch) Mono-crystalline, Anti-reflective coating used to reduce the reflectivity and enhance transmittance. Tempered Glass: 3.2mm?Low Iron and Anti-reflective coating glass increase the power output and mechanical strength of solar module. Mechanical load ≥2400Pa , transmittance ≥91.6% EVA: Anti-aging,Transmittance ≥91% , Adhesive Capacity >85% Back Sheet: high frame resistant & Double-sided fluorine TPT, to prevent destroying and water, it’s reflectivity ≥87%, peeling strength ≥ 40N/cm. Aluminum Frame: Anodized aluminum alloy to effectively improve the corrosion resistance and strength Junction Box: 6pcs 12A Diode + 90cm 4mm2 Solar Cable Life time: 25 years Power specification at 1kW/m 2, AM 1, 5 Output cable: multi contact connectors Warranty: 10years workmanship; Guarantee the power 90% in the first 12 years; Guarantee the power 80% in 25years. Certification: CE, TUV, IEC, MCS, CQC, CEC, CHUBB, BV, ISO

3> Features:

High Performance Solar Panel Monocrystalline Cells Low Reflection of Sunlight High Light Absorption Functions perfectly under low light or panel being partly shaded Top Range Alloys Anodized Frame with Corner Protectors ( guaranteed no rust ) CHUBB insurance company to guarantee the quality

4> Specifications

I-V Curves Electrical Characteristics

Maximum Power(Pmax)	260
Power Tolerance	0~3%
Open Circuit Voltage(Voc)	37.9
Short Circuit Current(Isc)	8.80
Maximum Power Voltage(Vmp)	30.9
Maximum Power Voltage(Imp)	8.42
Module Efficiency	15.98%
Max. System Voltage	1000VDC
Solar Cells	Monocrystalline156*156mm(6 inch)
Cells series	60pcs(6*10)
Bypass Diodes	6pcs 12A
Temperature Coefficients of Pmax	-0.47%/°C
Temperature Coefficients of Voc	-0.35%/°C
Temperature Coefficients of Isc	0.05%/°C
NOTC-Nominal Operating Cell Tepm.	45℃(±2°C)
STC Condition	1000W/m2, AM1.5, 25°C

Mechanical Characteristics

Dimension	1640*992*40(mm)
Frame	Anodized Aluminum Alloy
Construction	Front: High transmision 3.2mmTempered glass; Rear: White PET; Encapsulant: EVA
Output cables	4.0m㎡ 12AWG cable with weatherproof connectors.cable lengths 900mm
Weight	19.5KGS

Packing configuration

Container	40“HQ
Module dimension
