Product Details
Brand Name | Samsung | Place of Origin | China | |
Model Number | AMS495QA01 |
Product Description
Certification:ISO9001
AM - OLED 5.0'' Samsung LCD Panel 960×544 140cd/M2 For Portable DVD AMS495QA01
?
?
Quick Details:
?
Panel Brand :SAMSUNG
Panel Model :AMS495QA01
Panel Type :AM-OLED , OLED
Panel Size :5.0 inch
Resolution :960(RGB)×544 , qHD
Active Area :109.44×62.02 mm
Outline :116.54×73.92 mm
Brightness :140 cd/m2 (Typ.)
Contrast Ratio :6500 : 1 (Typ.)
?
Our headquarters located in Hong Kong and branch office in Shenzhen, Singapore, Malaysia and Canada.
We are professional distributor on LCD panels with our own warehouse and stock. Our goal is to provide worldwide supply chain solution based on integrity.
?
What we do for AMS495QA01 :
?
As the leading LCD distributor in China, we are strong at EOL panels and hard to find panels of famous Brands such as NEC, SHARP, AUO, SAMSUNG, LG, TIANMA, HITACHI, KOE etc.
Our products lines are widely used on medical apparatus, industrial control facilities, portable electrical impedance measurement apparatus, digital video camera display, vehicle equipment, aerospace equipment. Our products mostly cover small sizes, like 1.5", 2.0", 2.2", 2.5", 3.0", 3.5", 4.0", 4.2", 4.3", 4.7", 5.0", 5.5", 5.7", 6.0", 6.4", 7.0", 8.0", 10.1", 10.4", 12.1", etc. Most of them are original factory sealed carton packing. Moreover, we will do the brightness inspection of them by testing board.
?
N&S will be your powerful partner on LCDs in China. Here we are to quote your need.
<<
Panel Size : | 5.0 inch |
Dot Resolution : | 960(RGB)×544 (qHD) |
Pixel Configuration : | RGB Vertical Stripe |
Pixel Density : | 222 PPI |
Aspect Ratio : | 16:9 (H:V) |
Form Factor : | Flat Rectangle Display |
Dot Pitch : | 0.038×0.114 mm (H×V) |
Pixel Pitch : | 0.114×0.114 mm (H×V) |
Active Area : | 109.44×62.02 mm (H×V) |
Outline Dimension : | 116.54×73.92 mm (H×V) |
Outline Depth : | 1.66 (Typ.) mm |
Landscape or Portrait : | Landscape type |
Touch Panel : | Withou |
?
?
Trade Terms:
?
1.???? Payment terms: 100% by T/T when order confirmed
2.???? Lead time: 2-5 working days according to the order quantity
3.???? Sample lead time: within 3 working days after we get payment.
4.???? The price based on FOB Shenzhen,we will offer best discount according to order quantity.
5.???? Warranty:offer free spare parts within ONE year.
6.???? Offer OEM service for batch orders,to print logo and design box.
?
Our Advantages for AMS495QA01 :
?
LCD panels are sourced directly from manufacturers, OEM/CM's and worldwide business partners spanning five continents that include 40 countries, United States, Italy, Singapore, Korea, Taiwan, Germany, Thailand, Malaysia, Japan, etc. There are more than 540 enterprises. With our strong sourcing team and sufficient stock in our warehouse, and our professional Quality Control team and professional testing instruments, we can offer reliable quality panels at competitive price.
?
?
?
