Product Details
Brand Name | SHARP | Place of Origin | China | |
Model Number | LM057QC1T01 |
Product Description
Certification:ISO9001
5.7''inch 320×240 resolution 180cd/m2 for LM057QC1T01 Parallel Data Panel
Quick Details:
<
Panel No. : | LM057QC1T01 |
Dot Resolution : | 320(RGB)×240 (QVGA) |
Pixel Configuration : | RGB Vertical Stripe |
Pixel Density : | 70 PPI |
Aspect Ratio : | 4:3 (H:V) |
Form Factor : | Flat Rectangle Display |
Dot Pitch : | 0.120×0.360 mm (H×V)? |
Pixel Pitch : | 0.360×0.360 mm (H×V) |
Weight : | 200g (Typ.) |
Active Area : | 115.18×86.38 mm (H×V) |
Bezel Area : | 121.3×92.6 mm (H×V) |
Outline Dimension : | 154.6×114.8 mm (H×V) |
Outline Depth : | 8.3±0.5 mm |
Why purchase? LM057QC1T01? from N&S ELECTRONIC CO., LTD ?
Our headquarters located in Hong Kong and branch office in Shenzhen, Singapore, Malaysia and Canada.
We are professional distributor on LCD panels with our own warehouse and stock. Our goal is to provide worldwide supply chain solution based on integrity.
<<
Display Mode : | STN, Normally Black, Transmissive |
Brightness : | 180 cd/m2 (Typ.) |
Contrast Ratio : | 40 : 1 (Typ.) (Transmissive) |
Display Color : | Color () |
Response Time : | 450/100 (Typ.)(Tr/Td) |
Viewing Angle : | 50/50/35/60 (Typ.)(CR≥2) (L/R/U/D) |
Viewing Direction : | 6 o'clock |
White color Chromaticity : | Wx:0.320; Wy:0.330 |
Application:
Industrial display application handheld devicesOur Advantages for LM057QC1T01:
LCD panels are sourced directly from manufacturers, OEM/CM's and worldwide business partners spanning five continents that include 40 countries, United States, Italy, Singapore, Korea, Taiwan, Germany, Thailand, Malaysia, Japan, etc. There are more than 540 enterprises. With our strong sourcing team and sufficient stock in our warehouse, and our professional Quality Control team and professional testing instruments, we can offer reliable quality panels at competitive price.
What we do for LM057QC1T01 :
As the leading LCD distributor in China, we are strong at EOL panels and hard to find panels of famous Brands such as NEC, SHARP, AUO, SAMSUNG, LG, TIANMA, HITACHI, KOE etc.
Our products lines are widely used on medical apparatus, industrial control facilities, portable electrical impedance measurement apparatus, digital video camera display, vehicle equipment, aerospace equipment. Our products mostly cover small sizes, like 1.5", 2.0", 2.2", 2.5", 3.0", 3.5", 4.0", 4.2", 4.3", 4.7", 5.0", 5.5", 5.7", 6.0", 6.4", 7.0", 8.0", 10.1", 10.4", 12.1", etc. Most of them are original factory sealed carton packing. Moreover, we will do the brightness inspection of them by testing board.
Picture about LM057QC1T01:
N&S will be your powerful partner on LCDs in China. Here we are to quote your need.
