Home > Products > Sharp LCD Panel > Low Power Consumption 3.8 Inch Sharp LCD Panel LQ038J7DH52 For Medical Application
Low Power Consumption 3.8 Inch Sharp LCD Panel LQ038J7DH52 For Medical Application
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Hard Coating 5.7 Inch Sharp LCD Panel LQ057Q3DC12 Parallel RGB 115.286.4 mm
-
Commercial Sharp LCD Replacement Screen LQ084V1DG21 , 8.4 Inch Industrial LCD Panel Connector Interf
-
Professional Sharp Lcd Display Module , 8.4 Inch Small TFT Display LQ084V1DG22 262K
-
Full Colour Sharp LCD Module , 700g 10.4 Inch LCD Wall Screen LQ104V1DG21
-
High Vibration Proof 8 Inch Tianma LCD Displays For Personal Computer TM080SDH01
-
Long Backlight Life 3.7 Inch Sharp LCD Panel Parallel RGB LS037V7DD06
Product Details
| Brand Name | SHARP | Place of Origin | China | |
| Model Number | LQ038J7DH52 |
Product Description
Certification:ISO9001
Low Power Consumption 3.8 Inch Sharp LCD Panel LQ038J7DH52 For Medical Application
Product Descriptions:?
<
| Contrast Ratio : | 60:1 (Typ.)(Transmissive) 2:1 (Typ.)(Reflective) |
| Display Colors : | 262K (6-bit) |
| Response Time : | 20/35 (Typ.)(Tr/Td) |
| Viewing Angle : | 55/55/55/55 (Typ.)(CR≥2) (L/R/U/D) |
| Frequency : | 60Hz |
| Lamp Type : | WLED Without Driver |
| Signal Interface : | Parallel RGB (1 ch, 6-bit) , 39 pins |
| Input Voltage : | 5.0/3.3/15.0/-10.0V (Typ.)(VSHA/VSHD/VDD/VEE) |
Features For?LQ038J7DH52 TFT LCD Module:?
<
| Display Mode : | TN, Normally White, Transflective |
| Brightness : | 80 cd/m2 (Typ.) |
| Contrast Ratio : | 60 : 1 (Typ.) (Transmissive) |
| Contrast Ratio : | 2:1 (Typ.) (Reflective) |
| Display Color : | 262K (6-bit) |
| Response Time : | 20/35 (Typ.)(Tr/Td) |
| Viewing Angle : | 55/55/55/55 (Typ.)(CR≥2) (L/R/U/D) |
| Viewing Direction : | 1 o'clock |
| Reflectance Ratio : | 2.8/4% (Min./Typ.) |
| Sunlight Readable : | Sunlight Readable |
INTRODUCTION:
? ? ? The A LQ038J7DH52 TFT LCD Module screen monitor?is a fully-integrated, off-the-shelf unit (COTS) that combines high-performance Projected Capacitive Touch Technology (PCT or PCAP); in an industrial-grade LCD flat panel, with open Frame chassis mount industrial design. The PCAP industrial multi-touch displays with HMI interface provide full range of industrial-grade units with multi-function capabilities and brilliant displays. ?
? ? ? ?We also?provide full list for the Tianma LCD model series. ?We are?distributor for Commercial & Industrial LCD Panel not only for the Tianma LCD, but also the LCD panels for?Samsung, LG, Sharp, Innolux, AUO, BOE and more.?
| Signal Category : | TTL | |||||
|---|---|---|---|---|---|---|
| Signal Class : | Parallel RGB (1 ch, 6-bit) | |||||
| Input Voltage for Panel : | 5.0/3.3/15.0/-10.0V (Typ.)(VSHA/VSHD/VDD/VEE) | |||||
| Input Current for Panel : | 5.5/2.9/0.1/-0.1mA (Typ.)(ISHA/ISHD/IDD/IEE) | |||||
| Interface Type : | FPC | |||||
