Hydraulic Horizontal Continuous Casting Machine For 250mm Nickel Cupronickel Pipes

Hydraulic Horizontal Continuous Casting Machine For 250mm Nickel Cupronickel Pipes ?
?
?
Ⅰ. Specifications:
1. Types of casting specifications
* Nickel cupronickel
1.1 Pipes
a. Range of outer diameter Φ(28--300)mm
b. Range of wall thickness 4--80 mm
c. Number of production lines
1-- 8 lines( according to section conditions)
?
?
?
Ⅱ.Process:?

?
? ?Main equipments of production line
? ? ?melting furnace, holding furnace, mold, micro-travel reversible casting machine, synchronizing shearing machines * 2, winding machines* 3, hydraulic unit, cooling unit, and electromechanical control unit etc.
? ? ? ? * 2.1 For casting of pure metal or special requirements, subsurface channel-type smelting-holding combination furnace or controllable channel-type smelting-holding combination furnace can be adopted;

* 2.2 For producing round-shaped, tubular-shaped and special-shaped billets, cut-to-length synchronizing sawing machine can be adopted;

* 2.3 For producing round-shaped, tubular-shaped and special-shaped billets, the material stock platform for receiving and storing billets can be adopted.

?
Ⅲ. Equipment Components?List of ?Horizontal?Continuous Casting Production line for?Rod-Wire?

?
Ⅳ.?Date of Delivery:
? ??To be delivered within 75 days after the contract becomes effective.
?
Ⅴ. After-sales service
? ? 1. The main body of the equipment will have one year of free warranty, and special components shall be discussed separately;
? ? 2. During the trial-production period (within 3 months after equipment commissioning is finished), our company will dispatch a professional technician for follow-up service;
Within the warranty period, if fault occurs due to quality problem, our company will dispatch personnel to the site to solve the problem within 72 hours after receiving the notice;
After the warranty period of the equipment is expired, our company will offer effective solutions within 24 hours after receiving the notice, and will dispatch personnel for maintenance work if the user fails to solve the problem, only charging the cost expenses.
For annual overhaul of equipment, our company
