47 Windows 7 Infrared Multitouch (6 points) Screen Panel (WVT-M6R-47)

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	NWELIFE		Place of Origin	China
Model Number	NWELIFE

Product Description

Delivery Time:30 days
Certification:ISO9001,ISO14001

Multi Touch Screen Panel Overlay, Infrared Multi Touch, Windows7 Multitouch Screen
1. Main Features:
* Touch points: 6 touch points at a time
* Available Size: 24\'\' to 100\'\'
* Supports Win7 and TUIO Protocal
* 1 year free warranty
2. Applications
*Point-of-information kiosks, Desktop touch monitor
*Electronic catalogs, Ticket machine
*Gaming, POS, ATM, lottery, and amusement
*Industrial control rooms
*Computer-based training
*In-vehicles and transportation
*Medical instrument
3. Advantages:
*Available size range from 24\" to 100\". Customize upon requests from customer for any format display.
*Truly supports 6 precise touch points simultaneously without any ghost points.
*Compatible with windows 7, fully supports TUIO protocol in all-round way.
*USB connection to PC; Extremely low power consumption.
*Anti-Ambient Light; Performs greatly even in disadvantaged environments including all indoor activities and even under strobe lights in clubs.
*Effortless drags with refresh only 8-25 ms response time.
4. Certification:
*CE, RoHS
v id=\"StyleTableProd\">

Size
General Size	24?inch to?100 inch
Fit in with	Panel display device?
Performance
Touch Mode	Multi-touch
Resolution(Interpolation)	4096*4096
Linearity Error	<1.5mm
Response Speed	8-25ms
Mechanical
Input Method	Finger or gloved hand (rubber ,cloth or leather)
Touch Times	Unlimited
Touch Activation Force	No minimum touch activation force is required
Minimum Touch Object	2.5 mm X 2.5 mm
Vandal-proof	No break by 1-pound steel ball dropping from 130 cm high
Optical
Glass:	Without glass
Light Transmission	92%
Gloss	Antiglare surface (curved or flat): 95? ±? 15 gloss units or 65? ±? 15 gloss units?
Environmental?? ?????????????????????????????????????????????????????????????
Temperature	Working Temperature 0°C~+60°C,10%-90%RH
Storage Temperature: 0°C~+85°C,10%-90%RH
Relative Humidity	Operating Range: 0%~90% RH (no dew falls)
Storage Range: 0% to 95% RH (no dew falls)
Altitude?????????????????????	Up to 3,000m?
Ambient Light?????????	Direct sunlight 90°to ±30° to the display surface Touch detection operational
Direct sunlight all angles to display surface Free of false touch reports
Electrical
Operation Voltage	Typical +DC 5V, +4.75V to +5.25V
Power Supply	Size under 52a€?(include 52a€?)USB or PS/2 Interface, power ripple max.200mV rms
Size above 52a€?(52a€? not included): external AC-DC power adaptor
Interface	Full Duplex USB 2.0 (Full Speed) Plug and play compatible?
Serial RS-232. Baud Rate: 9600, 8 Data Bits, 1 Stop Bit, No Parity?
Current	Typical 150MA@+5VDC; 350mA, maximum
Power	<1.5W, operating current<300mA
Electrostatic Protection	15 kV air / 8 kV contact discharges (EN61000-4-2,1995 :Level 4)
Controller	Integration inside touch panel
Agency Approvals	CE, FCC, Rohs
Operating System
Operation System :windows 7.TUIO Protocol
