4 Megabit TX & 1 Megabit X 5 port network switch , Din rail installed Outdoor network switch
Negotiable
1 (Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
1.6Gbps 8 port unmanaged gigabit switch , Redundant input auto adaptive Din rail Network Switch
-
20 Gigabit Base TX and 4 Gigabit Combo port managed gigabit ethernet switch 50Gbps
-
High reliablity VLAN division RJ45 8 port poe switch , 1.6Gbps industrial unmanaged ethernet switch
-
10 port ethernet switch 7 * 100 Base TX + 1 * 100 Base FX High speed Network Switch
-
8 port fast ethernet switch 1.2Mpps Packet forwarding speed , 802.3u ethernet fiber switch
-
Stable Industrial Level 10 port Network Switch 8 + 1 port fast Ethernet Switch 0.775Kg 802.3x
Product Details
| Brand Name | Hengsion | Place of Origin | China | |
| Model Number | EII05-4E-1F-V |
Product Description
Certification:CE, FCC, ROHS
EII05-4E-1F-V
Unmanaged 4*100Base T(X)+ 1*100Base FX Industrial Ethernet Switch Dinrail Network Switch
Introduction
4*100Base T(X) fast Ethernet ports & 1*100Base FX fiber optic ports IEEE802.3/802.3u//802.3x, store and forward Wire speed forwarding capability of all ports make sure of non-blocking message forwarding. Automatic MDI/MDI-X crossover for plug-and-play Dual redundant power input, with overload protection and power reverse polarity protection. Support full-loaded operating temperature range -40 to 85℃. No fan, low power consumption design. Din rail corrugated metal casing, meet IP40 protection grade. Industrial Level-4 design.Specification
| Technology | |
| Standards | IEEE 802.3,802.3u,802.3x |
| Interface | |
| Megabit Ethernet port | 10/100 Base-T(X) auto-adaptive RJ45 |
| Megabit Fiber port | 100Base-FX (SC by default, ST/FC optional) |
| Power port | 5.08mm industrial terminal |
| Switching Features | |
| Processing Type | Store & forward, wire speed switching |
| Switching bandwidth | 1.6Gbps |
| Packet forwarding speed | 1.2Mpps |
| MAC Address | 1K |
| Buffer Memory | 512Kb |
| LED Indicator for | |
| Power, Ethernet port connection & running status, Fiber port connection & running status | |
| Power | |
| Input Voltage Range | 9-36VDC /12-24VAC redundant input |
| Idle Consumption | 0.16A@12VDC |
| Full -load Consumption | 0.37A@12VDC |
| Connection | 5.08mm industrial terminal |
| Protection | Overload Current Protection; Redundancy protection |
| Mechanical | |
| Casing | Strengthened corrugated metal casing |
| Protection grade | IP40 |
| Dimension(L*W*H) | 150*128.5*37mm |
| Installation | Din Rail |
| Weight | 0.55Kg |
| Environmental | |
| Operating Temperature | -40℃～+85℃ |
| Storage Temperature | -45℃～+85℃ |
| Relative Humidity | 5～95%,non-condensing |
| Industry Approvals | |
| EMI | FCC Part 15,CISPR(EN55022) class A |
|
EMS |
EN61000-4-2(ESD), Level 4 |
| EN61000-4-3(RS),Level 3 | |
| EN61000-4-4(EFT),Level 4 | |
| EN61000-4-5(Surge),Level 4 | |
| EN61000-4-6(CS),Level 3 | |
| EN61000-4-8,Level 5 | |
| Shock | IEC 60068-2-27 |
| Free Fall | IEC 60068-2-32 |
| Vibration | IEC 60068-2-6 |
| Warranty | |
| Warranty Period | 5 years |
Ordering Information
| Models | Port Interface | |||
| 1000Base FX SFP | 10/100/1000Base T(X) | 100Base F(X) | 100Base T(X) | |
| EII05-4E-1F-V | 0 | 0 | 1 | 4 |
Optional Accessories (can be purchased separately)
? DR-30D12, Din-Rail power supply, 85-264VAC/120-370VDC@12VDC , -20 to 60℃ operating temperature
? GS-12D12, Power adaptor, 100-240VAC@1A12VDC, -20 to 50℃ operating temperature
Package Checklist
? Ethernet switch
? Hardware installation guide(printed)
? Warranty Card
Dimension
Connection
