Product Details
| Brand Name | Hengsion | Place of Origin | China | |
| Model Number | MNB28G-24E-4G |
Product Description
Certification:CE, FCC, ROHS
?
MNB28G-24E-4G
Managed 24*1000Base T(X) + 4*1000 /10000Base SFP fiber optic port Ethernet Switch
?
Introduction
Websmart?MNB28G-24E-4G provides 4*1000Base-TX or 10000Base-TX fiber optic ports and 24*10/100/1000BaseT(X) Ethernet ports.
No fan, low power consumption design; Support Ethernet redundant Ring protocol( recovery time＜20ms), with complete security and QoS policies;
Support VLAN division, port mirroring, and port rate limiting; Support broadcast storm suppression, flow control, and centralized management and configuration by WEB,CLI,SNMP;
MNB28G Series has a wealth of operational features which can meet user’s networking requirements of multi-service integration, security, scalability and manageability.
The wide operating temperature range and port surge protection design are ideal for application in large flow real-time outdoor environment, and are widely used for occasions including enterprise, intelligent building, cafe, community access or gathering etc., and for industries like finance, education and government etc.
?
?
Features:
? 24* 10/100/1000Base T(X) Ethernet ports and 4*1000Base-FX or 10GE SFP fiber optic ports.
? Support Ethernet redundant Ring protocol( recovery time≤20ms)
? Wire speed forwarding capability of all ports make sure of non-blocking message forwarding.
? Support 802.1x authentication, VLAN, and broadcast storm suppression.
? Support IEEE/802.3x full duplex flow control and Backpressure half duplex flow control.
? Loop detection and Port+ IP+MAC binding.
? Port traffic monitoring and fault event alarming
? Support WEB visual interface, support SNMP management.
? Automatic MDI/MDI-X crossover for plug-and-play
? Overload protection and power reverse polarity protection.
? Full-loaded operating temperature range -20 to 70℃.
? 19” 1U Rack Mount installation
?
?
Specification:
