Light Weight RGB Indoor Full Color LED Display Hire IP40 With Long Life Time

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Glux		Place of Origin	China
Model Number	MOtn

Certification:CE/ROHS/UL/TUV

Light Weight RGB Indoor Full Color LED Display Hire IP40 With Long Life Time?

1. Type: Indoor LED?rental display;

2. Panel Size(W x H x D):?1000*500*45mm;

3.?Color Temperature (after calibration) (K): 6500;

4.?Weight?capacity: 1000kg/m2

5. Application: indoor concerts, ceremonies, festivals, TV programs,?etc.

Specifications:

	Carbon fiber panel frame Carbon fiber is lighter weight than metallic aluminum but stronger than iron and steel, as well as other characters of high weather-resistance, corrosion-resistance, high mechanical stability, durability and no deformation. MOsn with carbon fiber is light weight and small dimension which can effectively reduce transportation and labor cost.
	Low wind resistance and high transparency Transparent mesh design is easy for the ventilation and lowering the wind resistance, suitable for outdoor large scale setup.
	LCD display with self-test function and indicating working status The panel self-test button is convenient for failed LED and color uniformity testing with only power on. LCD display includes the working status of power1 and power2, working temperature and working hours.
	45 degree oblique angle design, seamless connection sticky tape Double-side 45 degree oblique angle design, support 90-180 degree assembly. Sticky tape support seamless connection between panels.

Main Parameters:

Parameter Type	MOtn10	MOtn15
?	?	?
Pixel Pitch(mm)	10.4	15.6
Pixel Density (dots/m2)	9216	4096
Pixel/Panel(W*H)	96*48	64*32
Brightness Max(cd/m2)	1000	1000
Grey Scale (bit)	16	16
Refresh Rate (Hz)	1000	1000
Frame Rate(Hz)	30/70	30/70
Contrast	4000:1	4000:1
Scan Mode	1/6	1/2
Color Temperature (after calibration) (K)	6500	6500
Horizontal / Vertical Viewing Angle (°)	H140/V140	H140/V140
Panel Size (W x H x D) (mm)	100050045	100050045
Module Size (W x H ) (mm)	500*125	500*125
Weight (kg/panel)	4.8	4.8
Protection	IP40	IP40
Power Supply	Dual power supply	Dual power supply
Working Voltage(V)	AC100-240V/50/60Hz	AC100-240V/50/60Hz
Max Power Consumption (W/pc)	150	150
Avr Power Consumption (W/pc)	75	75
Working Temperature	-20Co/40Co	-20Co/40Co
Cabinet Material	Carbon fiber	Carbon fiber
Panel weight bearing capacity	1000kg	1000kg
Signal Cable	CAT5-1000M	CAT5-1000M
Video Signal Input Interface	DVI/HDMI/HDSDI	DVI/HDMI/HDSDI
Life Time (h)	100000	100000

By using this products, we have successfully operated the following projects:

??2011 Summer Universiade Opening Ceremony ? ? ??
