3G WCDMA Router

Place of Origin	China

>>| E-Lins 3G WCDMA RouterE-Lins 3G routers covers 3G WCDMA,Website: , 3G CDMA2000 EVDO, 3G TD-SCDMA.?For single sim 3G router, the main models are H685, H685m, and H820.ModelSim Slot QuantityModule QuantityEthernet PortOthersH68511WAN RJ45 * 1LAN RJ45 * 1With serial port and DIO port for optionH685m11WAN RJ45 * 1LAN RJ45 * 1H82011WAN RJ45 * 1LAN RJ45 * 4With serial port and DIO port for option>>| Typical Topology>>| Industrial 3G WCDMA Router SpecificationWirelessCompatible Mobile NetworksUMTS WCDMA (HSUPA/HSDPA/HSPA/HSPA+/DC-HSPA+)GSM EDGE/GPRSCellular FrequencyUMTS/HSDPA/HSUPA/HSPA/HSPA+/ DC-HSPA+ (WCDMA/FDD): 850/1900/2100 MHz, option for 850/900/1900/2100Mhz/1700Mhz/AWS;Quad-band EGSM 850/900/1800/1900;BandwidthDC-HSPA+: Downlink 42Mbps, Uplink 5.76Mbps;HSPA+(H): Downlink 21Mbps, Uplink 5.76Mbps;HSPA+(L): Downlink 14.4Mbps, Uplink 5.76Mbps;HSUPA: Downlink 7.2Mbps, Uplink 5.76Mbps;HSDPA: Downlink 7.2 Mbps, Uplink 384k bps;WCDMA/UMTS: Downlink/Uplink 384 kbps;EDGE: Downlink 384 kbps, Uplink 118 kbps;GPRS: Downlink 108 kbps, Uplink 42.8 kbps;Notes: the bandwidth is peak value. Real value depends on carrier network support.Network and Band Lock Feature (Option)Default is unlocked, can use this feature to lockMain Features and PerformanceUSB HostNoSMS and SMS/Voice Control and AlarmReceive and Send the SMS;WAN Cell APN configuration via SMS;SMS/Voice Control and Alarm. SMS or Call to control router to be online, offline, reboot, signal and status monitor; SMS is default feature, Voice is optionGPS (Option)GPS featureDTU (Option)With DTU feature (Serial to Cellular Gateway feature, RS232 or RS485 port option).Details:Serial Baudrate: 300bps, 600bps, 1200bps, 2400bps, 4800bps, 9600bps, 19200bps, 38400bps, 57600bps, 115200bps;Serial Parity: none, even, odd;Serial Databits: 7, 8;Serial stopbits: 1, 2;Serial flow control: none, hardware, software;Mode: Server (up to 4 server centre, can OEM to be more), Client;Protocol: TCP, UDP ;Heart Beat : Yes;VPNPPTP, L2TP, IPSec, GRE, Tunnel　(PPTP server, PPTP client, L2TP client, IPSec client, IPsec server), OpenVPN is optionOpenWRT (Option)OptionalVRRP (Option)OptionalRouteStatic Route;Optional for Dynamic Route (BGP, BGPD, OSPF, Zebra, Rip);SNMPSupport V1, V2. V3VLANSupport multi-LAN IP address, support two IP addressWi-Fi(WLAN)Optional, 802.11b/g/n; 150Mbps default.Can be used as AP and client;Frequency from 2.4GHz to 2.483GHz,Access Points, Routers and Gateway Server Applications, wireless up to 254 PC usersFail Over Redundancy (network Backup feature)Auto-dial feature, keep alive link;LCP, ICMP check;Built-in watch dog;Cellular (2G/3G/4G), RJ45 WAN (xDSL, DHCP, Fixed IP), WiFi client three line redundancy;Two H685/H820 dual sim same network(Network1+ Network1);Two H685/H820 dual sim two network (Network2+ Network 2);Two H685/H820 dual sim dual mode network (WCDMA+CDMA2000, WCDMA+LTE, CDMA2000+LTE);Cold Backup is default, Hot Backup is option;Cold Backup=WAN RJ45 and Cellular WAN not online at the same time. One line online and the other line standby, switch freely with triggers;Hot Backup=WAN RJ45 and Cellular WAN are online at the same time. Data goes the main line, and switch to the other line. Hot Backup switch time is shorter than Cold Backup.POE (only for H685)POE for LAN/WAN RJ45 (use with POE adapter)Firmware updatesupport firmware update locally or remotely (LAN, WiFi and OTA WAN)Sysloglocal and remoteDDNSYesDHCP ServerYesOthersDNS proxy;Optimized EMC design;Real-time clock (NTP, support update with defined hours);WAN/LAN/Memory statistics;Local/remote profiles backup and retrieve;Firewall;Management SystemOptionInterfaceLAN/WANEthernet RJ45 LANH685*1 or 2, H820*4Ethernet RJ45 WAN*1Antenna2 antenna for Wi-Fi (detachable, SMA interface * 1, Internal *1)3 antenna for Cellular and GPS (detachable, 50Ω SMA female interface), Cellular support diversity receiving (MIMO) optionLedSYS*1VPN*1Cell Signal*1Cell*1WAN*1LAN*1 (H685), ?LAN (10/100M) 1, 2, 3, 4 (H820)WiFi*1ButtonResetConsole1 console portSerial portRS232 or RS485 built-in terminal block interfaceIO Port (option)2ManagementEasy to use and management;Web/Telnet/SSH/CLI, support remote managementSMS;SNMP;RMS (Remote Management System)At commandSupportedUIM/SIM Card SlotSupport 1.8V/3V UIM/SIM cards, one sim card slotDC JackTwo types of input jack for DC2.5mm DC jack * 1Terminal Block * 1PowerPower supplyDC5V-50V / DC5V-60V, typical DC 9V1A or 12V1A, 12v CAR USE;DC5V~40V is the default, DC5V~50V is the optionCurrentIdle: about 100mA@12VDCCommunication: about 260mA@12VDCSoftwareDevice ManagementWEB interface (Internet Explorer v6 or Later; Mozilla Firefox v1.5 or Later, or other Java-enabled Browsers, Chome, Opera, Sarafi, etc.)Minimum System RequirementsWindows, Linux, Mac OS, IOS, Symbian, Android, other OS support web browser;Network Interface CardPhysicalOperating TemperatureStorage Temperature: -40 ~ 85°CWorking Temperature: -30 ~ 75°CHumidity95% Maximum (Non-condensing)DimensionsH685 ModelPCBA: 96mm x 56mm x 14mmWith case: 100mm x 60mm x 21mmH820 ModelPCBA: 156mm x 104mm x 20mmWith case: 168mm x 104mm x 25mmWeightH685 Model220g (not including the antenna)330g (including the antenna)650g (including all accessories, without package)H820 Model455g (not including the antenna)550g (including the antenna)850g (including all accessories, without package)ColorMetal Gray-Black, OEM is availableOthersWarranty1 Year default. Option extends to 5 years maximum.Package ContentsH685/H820 Series 3G WCDMA RouterEthernet CablePower AdapterAntennaOthers depends on option features
