Stainless steel 316L Mini - type Tee Three - way Diaphragm Valve for phamacy hygienic process
- T/T L/C D/P D/A
- 7 days
You May Like
-
Sanitary multiport Sanitary Diaphragm Valve for pharmaceutical industry
-
Stainless steel 316L Multiport Phamacy Sanitary Diaphragm Valves with hand wheel of BPE standard
-
Hygienic Aseptic Connection Stainless Steel Sanitary Fittings From 1\"-4\" for tank bottom union
-
Electric Clamped Direct Sanitary Diaphragm Valve self - adjusting for flow regulation
-
Hygienic Aseptic Flange Set Stainless Steel Sanitary Fittings DN11864 Sanitary Thread union
-
Sanitary Polish ASTM 304 / 316L welded seamless Stainless Steel tube for food
Product Details
| Brand Name | DONJOY | Place of Origin | China | |
| Model Number | NO. MINI-VGM0S2, NO.MINI-VGM0Q2 |
Product Description
Stainless steel 316L Mini - type Tee Three - way Diaphragm Valve for phamacy hygienic process
Specifications
|
Product Name: |
316L SS Mini-type Tee Diaphragm Valve for phamacy hygienic process |
|
Valve Body Material: |
SS316L |
|
Seal Material: |
Single sillcone gasket/ Adhesive PTFE+EPDM/Two pieces PTFE+EPDM |
|
Max Working Pressure: |
10 Bar |
|
Max.Working Temperature: |
150 degree C |
|
Availably? size: |
1/4”-3/4”, DN6-DN15 |
|
Availably connection: |
Clamp/weld/thread/special connection |
|
Availably standard: |
3A/BPE/DIN/ISO/IDF |
|
Operation: |
Manual or pneumatic is optional |
| Structure: | Mini model |
|
Availably structure: |
Straight, tee, U-type, tank bottom |
|
Control: |
Smart valve positioner / C-TOP control / position sensor |
|
Certificate: |
3A/54-02 (1580), PED/97/23/EC, FDA.177.2600 |
|
Application scope: |
Dairy,food, beverage, pharmacy, cosmetic, etc |
Description
Various configuration of Diaphragm valve
1.????? Didaphragm valve with Pisitioner / Process Controller (IL-TOP)
2.????? Diaphragm valve with Control Unit (C-Top)
3.????? Valve position Regulator
4.????? Position Sensor Module
5.????? Plastic Handle
6.????? Stainless steel handle
7.????? Stianless steel acutor
8.????? Electric Diaphragm valve
9.????? Plastic Acutor
10.? Body: Casting / Forging
Packaging Details
Bubble pack for each valve.
Outside packing are carton or plywood cases.
Or as per the request of customers.
Delivery details
Usually within 20 days after receiving T/T down payment.
