Product Details
| Brand Name | DONJOY | Place of Origin | China | |
| Model Number | NO.VGM0S2, NO.ZZ-K |
Product Description
Direct - Way Sanitary Diaphragm Valve with Plastic Hand Wheel
Specifications
|
Product Name: |
316L SS Direct way Clamp Diaphragm Valve with Plastic Handwheel for phamacy hygienic process |
|
Valve Body Material: |
SS316L |
|
Seal Material: |
Single sillcone gasket/ Adhesive PTFE+EPDM/Two pieces PTFE+EPDM |
|
Max Working Pressure: |
10Bar |
|
Max.Working Temperature: |
120 degree C |
|
Available? size: |
1''-4'', DN25-DN100 |
|
Available connection: |
Clamp/welding/thread/special connection |
| Operation: | By hand wheel |
| Handle wheel: | Stainless steel or plastic is optional |
|
Available standard: |
3A/BPE/DIN/ISO/IDF |
|
Operated: |
Manual,Pneumatic |
|
Availably structure: |
Straight, tee, U-type, tank bottom |
|
Control: |
Smart valve positioner / C-TOP control / position sensor |
|
Certificate: |
3A/54-02 (1580), PED/97/23/EC, FDA.177.2600 |
|
Application scope: |
Dairy,food, beverage, pharmacy, cosmetic, etc |
|
Packaging Details: |
Bubble pack for each valve. Outside packing are carton or plywood cases. Or as per the request of customers. |
|
Delivery details: |
Usually within 20 days after receiving T/T down payment. |
Description
Various configuration of Diaphragm valve
1.????? Didaphragm valve with Pisitioner/Process Controller(IL-TOP)
2.????? Diaphragm valve with Control Unit(C-Top)
3.????? Valve position Regulator
4.????? Position Sensor Module
5.????? Plastic Handle
6.????? Stainless steel handle
7.????? Stianless steel acutor
8.????? Electric Diaphragm valve
9.????? Plastic Acutor
10. ? ?Body: Casting / Forging
Packaging Details
Bubble pack for each valve.
Outside packing are carton or plywood cases.
Or as per the request of customers.
Delivery details
Usually within 20 days after receiving T/T down payment.
