Home > Products > Waste Tire Recycling Plant > 4kw Waste Tire Recycling Plant Tyre Crushing Machine 10 - 100 Mesh
4kw Waste Tire Recycling Plant Tyre Crushing Machine 10 - 100 Mesh
Negotiable
/ Set
1 Set(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Two Roll Mill Waste Tire Recycling Plant Shredder Machine High Efficiency
-
Automatic Tire Recycling Equipment Shredding Crusher Plant 20 Pcs Blades
-
Tire Shredder Rubber Shredding Machine Crush 50MM 50MM Block
-
Customized Waster Rubber Recycling Plant Tire Shredding Equipment
-
22Rpm Rubber Shredding Machine / Rubber Recycling Machinery Eco Friendly
-
Alloy Steel Tire Rubber Shredding Machine With 20 Pcs Baldes
Product Details
| Brand Name | Zhenya | Place of Origin | China | |
| Model Number | ZY201601 |
Product Description
Certification:CE
4kw Waste Tire Recycling Plant Tyre Crushing Machine 10 - 100 Mesh
Specification:
Product Description
Continuous waste rubber scrap rubber tire recycling plant
?
1.?The working process:
Waste tire---Tire circle cutting---Rims separating---Tire cutting---Tire shreding---Rubber
crushing
--- Magnetic separating ---Rubber powder
2.?Function and technical parameter:
1). Tire circle cutter ( to cut and open the joint of tire's side and top )
Name |
Motor power |
Weight |
Capacity |
Tire specification |
Tire circle cutter |
4kw |
650kg |
40pcs/h |
650-1200mm(Both reinforced and nylon tires) |
2). Rims separator: it is used to separate the steel rims around the tire to
avoid the harm to?the machine.
Name |
Motor power |
Weight |
Capacity |
Rims separator |
7.5kw |
1300kg |
100pcs/h |
3). Tire strip cutter: it is used to cut the tire cirlce into strips 5x8 cm .
Name |
Motor power |
Weight |
Capacity |
Cutting size |
Tire strip cutter |
4kw |
850kg |
2.5t/h |
5x8cm |
4). Tire slice cutter: it is used to cut the strips into small chunks about 3.5
cubic centimeter.
Name |
Motor power |
Weight |
Capacity |
Cutting size |
Tire slice cutter |
4kw |
800kg |
0.8t/h |
3x5x8cm |
5). Rubber crusher: is used togrind the chunks into smaller mesh powder
through the vibrating?screen as youneed.
Model |
Drum diameter |
Drum length |
Front roll linear |
Roll speed ratio |
Max roller spacing |
Motor power |
XKP-350 |
300mm |
500mm |
17.6m/min |
1:1.38 |
10mm |
20kw |
XKP-400 |
400mm |
600mm |
21.6m/min |
1:1.38 |
10mm |
30kw |
XKP-450 |
450mm |
760mm |
25.3m/min |
1:1.39 |
10mm |
37/45kw |
XKP-560 |
560mm |
800mm |
28.6m/min |
1:1.41 |
10mm |
55/60kw |
6). Magnetic separator: is used to separate the short wire from the powder
Name |
Motor power |
Weight |
Specifications |
Magnetic separator |
1.5kw |
400kg |
Permanent magnet |
