Hydraulic Tyre Cutting Machine Production Line Making Rubber Powder

It could be applied to cut all kinds of rubber blocks and strips. It is good for cutting rubber tyre,
rail tyre, rubber strips etc.
?
Structure and principle
?
It mainly consists of the motor, cutting blades, static blades, frame, oil cylinder, hydraulic
system, control box, etc.
?
Its basic principle is: The oil cylinder and hydraulic system are driven by a motor. Put the tyre
without wire bead on the stand of the static blades. The tyre is fixed by locking arms tightly
then cut by the blades driven by oil cylinder. The tyre is cut into several blocks, which will be
more easily crushed or shredded for the next process.
?
?

1. First, we need to cut and draw out the bead wire of the tire by the Compound Tire Cutter
and Extractor,
?
2. Then we can put the tire into the Tire Crusher by the conveyor, the tire will be crushed
into small pieces with the size of 50x50mm.
?
3. And those small pieces will be conveyed to the Secondary Crusher to be crushed into
small particles of 6-12mm.
?
4. Now we need a Magnetic Separator to separate the steel fiber from the rubber particles,
and a Square Magnetic Vibrator to separate the coarse fiber from the rubber particles by
vibrating.
?
5. The coarse fiber will be collected in a box and the rubber particles will be delivered to a
third Rubber Shredder to be shredded smaller of 1-4mm.
?
6. And then we need a Static Vibrator to gather the small fiber into clumps by static force,
and to filter the rubber particles by screen.
?
7. The fiber clumps will be stored in the Fiber Collecting Machine by conveyor, while the
rubber particles will be sent to the Airflow Classifier,
?
8. The residual fiber will be blowed to the Fiber Collecting Machine by the Airflow Classifier,
and the purified rubber particles will be collected by the Storage Bin,
?
9. And then be delivered to the Rubber Grinder, so the rubber particles will be grinded
into rubber powder.
?
10. Then the rubber powder will be separated by the Three-layer Vibrator according to its
size, and be packed automatically by the Packing Machine.
?
11. The exhaust gas and dust will be collected by the Cyclone Collector, then the dust will
be absorbed by the Dust Separation Machine,
?
12. while the gas will be filtered by Activated Carbon in the Air Purifier and be emitted to Air.
?
?
The whole recycling production line
?
