Home > Products > HD LED Display > Commercial Full Color P5 HD Led Screen Rent Video Wall Displays 1 / 16 Scan
Commercial Full Color P5 HD Led Screen Rent Video Wall Displays 1 / 16 Scan
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
P4 Full Color Indoor Advertising LED Display Screen For Stage Concert
-
Die Casting Aluminum P3.75 Indoor Stage Led Display Screen HD Video Performance
-
Full Color Rental Indoor LED Screens P5 LED Module Display , High Definition
-
Custom Rent Curtain Led Screen Pixel Pitch 5mm Indoor Led Display
-
Commercial Dynamic RGB Indoor LED Screens , Led Tv Advertising Displays
-
Commercial Advertising Indoor LED Screens P5 RGB LED Display H140 / V120
Product Details
| Brand Name | LIGHTIN | Place of Origin | China | |
| Model Number | LTI-PH5 -001 |
Product Description
Certification:CE/ISO9001/FCC/Rohs
Commercial Full Color P5 HD Led Screen Rent Video Wall Displays 1 / 16 Scan
P5 HD LED display ?Main advantages:
1 . New mask design makes LED light almost zero reflection, which ensures the screen displaying effect;
2 . The cabinet of unit modules adopts to high-temperature spraying technology, the antirust function is greatly improved;
3 . Module surface flatness ± 0.2mm, the entire screen has good flatness;
4 . High uniformity display color;
5 . For improving the service life, PCB is made by wave soldering process with the green oxygen isolation layer, which prevents the line of moisture and oxidation.
6 . Service efficiency of the screen switch power supply is increased substantially, which reduces power failure rate;
7 . Using fishbone bus line greatly reduces the contact problem .
8 . IP65 grade for high performance waterproof and dustproof capability.
9 . -25°C – 65°Cworking environment for outdoor display , adapted to the harsh environment.
| P5 HD LED display for digital commercial small radiation large viewing angle 1 / 16 scan | ||
| Unit Module | Item | parameter |
| Model | ?P5 - 16S | |
| Module size | 320mm x160mm | |
| Pixel Pitch | 5mm | |
| Pixel Density | 40000dots / m2 | |
| Pixel Configuration | 1R1G1B | |
| Package mode | SMD3528 | |
| Module Resolution | 64dots (W)*32dots(H) | |
| Max power consumption | 25W | |
| Module Thickness | 14.27mm(without magnet) 26.6mm (with magnet ) | |
| Module Weight | 0.21kg | |
| Driving Method | Constant Current Driving | |
| Scan Method | 1 / 16scan / 1 / 8scan | |
| Interface Way | HUB75-A | |
| Brightness | ≥ 1600cd / m2 | |
| Unit Module | dimension | 640mm x 640mm |
| Quantity of Module | 16 | |
| Thermal discharge | fan 2pcs | |
| Power supply Mode | 5V/40A x 2pcs | |
| Pixel per cabinet | 128mm x 128mm | |
| Thickness | 85mm | |
| Optimal Viewing Distance | 5M-30M | |
| Optimal Viewing angle | 160°(W)120°(H) | |
| Enviroment Temperature | Storage :-35℃-+85℃ work :-20℃-+50℃ |
|
| Power | Relative Humidity | 10%-95% |
| Operating Voltage | AC220V±10% | |
| Average power consumption | ≤ 1180W / m2 / ≤ 270W / m2 | |
| Max power Consumption | ≤ 500W / m2 / ≤ 800W / m2 | |
| Current | ≤ 20mA (Single LED ) | |
| Control system | CPU | Pentium4 or above P4 or above |
| Operate system | WIN98/2000/NT/XP | |
| Control Mode | Synchronization with PC | |
| Main technical parameter | Driving Device | IC Constant current driving |
| Refresh Rate | ≥ 400HZ | |
| Gray/Color | RGB each 256 grade, can display 16.7M clolor | |
| MTBF | ≥ 9000hours | |
| Power Switch | Automatic Switch | |
| Display Mode | 800 x 600/1024 x 768 | |
| Trade terms : | 1. Payment:T/T,30% deposits before production,70% balance to be paid before delivery . |
| 2. Shipping freight are quoted under your requests . | |
| 3. Shipping port: Shenzhen,mainland China . | |
| 4. MOQ:1SQM . | |
| 5.Package : Wooden packing and flight packing . | |
| About Technology : | 1. We provide the technology training for free, which contains the operation training and maintenance training at our factory. |
| 2. We will send our engineers to your country by negotiation. | |
| 3. We provide CAD drawing on how to fix up the display for free and some other expert suggestion. | |
| 4. We will send our engineers to your place if we are expected after our negotiation. |
