Home > Products > HD LED Display > Custom P3mm Multi Color Indoor Full Color Led Video Display For Shopping Mall
Custom P3mm Multi Color Indoor Full Color Led Video Display For Shopping Mall
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
P4 Transparent HD LED Display Advertising Board For Stage Background
-
Aluminum HD SMD 3 In1 Indoor Advertising Led Display P4 For Stage Concert
-
High Resolution P3.91 Stage LED Screens 500 x 1000 mm Die-casting Aluminum Cabinet
-
High Definition P6 Large Indoor Led Tv Advertising Displays With 140 Viewing Angle
-
P10 Outdoor Full Color LED Display Module 160mm160mm Led Video Screen Rental
-
High Definition P8 Outdoor Full Color LED Display Board For Advertising
Product Details
| Brand Name | LIGHTIN | Place of Origin | China | |
| Model Number | LTI-PH3.91 -001 |
Product Description
Certification:CE/ Rohs /FCC/ ISO9001
Custom P3mm Multi Color Indoor Full Color Led Video Display For Shopping Mall
Product feature :
?
1. High color consistency and contrast : The module mask is designed with rubber material, no screws needed, high color contract and flatness.
2. Light and slim: cabinet size 512mm × 512mm × 87mm, weight 12.5kg , the thinnest point is only 20mm.
3. Easy installation and dismantling , without any tools , it takes only 6 seconds to assemble one cabinet , any cabinet within the screen is free of assembly and dismantling .
4. High structure performance: easy connection of each components , modules and HUB card without flat cables , modules and systems without power cable .
5. Easy maintenance : only 5pcs screws to lock the module, each module can be dismantled and installed without taking out power, system card and any other components.
6. High heat stability : great heat dissipation design, with heat conduction rubber , PCB aluminum casing and dissipation system.
7. High flatness precision : with die-cast aluminum technology, the tolerance of cabinet and module are controlled within 0.1mm, screen flatness and split joint gap are controlled within 0.3mm.
8. Beautiful appearance : humanized arc handle design, it's a perfect show of technology and art.
9. High-end display effect : high refresh , high gray scale , high color contrast , and high quality picture effect.
| P3 indoor HD LED display Die Cast Aluminum Cabinet full color self adjusting system techincal parameters | ||
| Unit Module | Item | parameter |
| Model | ?P3 - 16S | |
| Module size | 192mm x 96mm | |
| Pixel Pitch | 3mm | |
| Pixel Density | 111111dots / m2 | |
| Pixel Configuration | 1R1G1B | |
| Package mode | SMD2121 | |
| Module Resolution | 64dots (W) * 32dots(H) | |
| Max power consumption | 18w | |
| Module Thickness | 14.75mm(without magnet) 26.63mm (with magnet ) | |
| Module Weight | 0.16kg | |
| Driving Method | Constant Current Driving | |
| Scan Method | 1 / 16scan | |
| Interface Way | HUB75-A | |
| Brightness | ≥ 1500cd / m2 | |
| Unit Module | dimension | 576mm x 576mm |
| Quantity of Module | 18 | |
| Thermal discharge | fan 2pcs | |
| Power supply Mode | 5V / 40A x 3pcs | |
| Pixel per cabinet | 192mm x 192mm | |
| Thickness | 85mm | |
| Optimal Viewing Distance | 3M - 20M | |
| Optimal Viewing angle | 160°(W)120°(H) | |
| Enviroment Temperature | Storage :-35℃-+85℃ work :-20℃-+50℃ |
|
| Power | Relative Humidity | 10 % - 95 % |
| Operating Voltage | AC220V ± 10 % | |
| Average power consumption | 180W / H | |
| Max power Consumption | ≤ 360W / m2 | |
| Current | ≤ 20mA (Single LED ) | |
| Control system | CPU | Pentium4 or above P4 or above |
| Operate system | WIN98 / 2000 / NT / XP | |
| Control Mode | Synchronization with PC | |
| Main technical parameter | Driving Device | IC Constant current driving |
| Refresh Rate | ≥ 400HZ | |
| Gray/Color | RGB each 256 grade, can display 16.7M clolor | |
| MTBF | ≥ 9000hours | |
| Power Switch | Automatic Switch | |
| Display Mode | 800*600 / 1024*768 | |
