Home > Products > Outdoor LED Screens > High Refresh DIP 1R1G1B Outdoor LED Screens P10 Led Display Board For Advertising
High Refresh DIP 1R1G1B Outdoor LED Screens P10 Led Display Board For Advertising
Negotiable
/ Kilogram
1 Kilogram(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
P6.25 Front Service Rental LED Display Mobile Advertising , Led Wall Display Screen
-
Custom Rental P5 LED Advertising Display Indoor Led Video Wall Screen 1R1G1B
-
High Brightness Indoor LED Screens SMD Led Advertising Display Rental 1R1G1B
-
Professional HD Stage LED Screen Display For Entertainment Event 160000dots/m2
-
High Definition P2.5 Rental Led Display , SMD2121 Stage Background Led Screen
-
Super Bright P6.25mm Outdoor Full Color Led Display Rentals 25600dots/m2
Product Details
| Brand Name | LIGHTIN | Place of Origin | China | |
| Model Number | P10-0508 |
Product Description
Certification:CCC CE ROHS ISO
High Refresh DIP 1R1G1B Outdoor LED Screens P10 Led Display Board For Advertising
Specification :
Pixel Configuration: DIP 1R1G1B ? Pixel Pitch: 10m ? Module Resolution: ?32× 16?pixel dots ? Module size: 320mm x 160mm ? Cabinet Resolution: 96 × 96?pixel dots ? Cabinet Size: 960?x 960?x 150?(mm) ? Cabinet Weight: 43kgFeatures:
Louvered-face and mask-face panels are avaiable. ? The whole sign is separated into pieces for transportation. ? Modular Design allows the sign to be built in various size. ? LED module is sealed twice for good weather resistance. ? Forced air ventilation and natural heat-dissipation system. ? Easy access from double-layer weather-resistant rear doors.Product advantages:
1) Price Advantage: we have the best competitive price at the market, also have the same even better quality.
2) Quality advantage: From material to finished product, from design to produce, we control all steps
3) Service advantage: Better service at same situation, better cooperation at same service
| . | Part No. | P10 LED DISPLAY Screen |
| 2. | LED chip | Taiwan Epistar /Silan/Cree/Cree Cotco |
| 3. | Physical Pixel Pitch | 10mm |
| 4. | Physical Pixel Density | 10000dots/m2 |
| 5. | Pixel composition | 1Red, 1Green,1Blue |
| 6. | Moduel Size | 160*160mm |
| 7. | Moduel resolution | 16*16dots |
| 8. | Cabinet thickness | < 170 mm |
| 9. | Bracket of cabinet | Easy to install onto the LED cabinet and unistall . |
| 10. | Brightness | ≥ 6500 nits |
| 11. | Colors | 16.7million |
| 12. | Viewing angle | Horizontal ≥120°, Vertical : ≥ 45° |
| 13. | Viewing distance | 10m -300m |
| 14. | Soft Rubber Mask | To protect player and LED display itself . |
| 15. | Scan frequency |
≥600 Hz There will be one receive card in each cabinet ,so that the LED display won't sparked .Also it is very easy to move and connetct |
| 16. | Video Frame Rate | ≥150 fps |
| 17. | Color temperature | 6500°K to 9500°K adjustable |
| 18. | Control method | Controlled by PC, synchronous display |
| 19. | Life span( half brightness) | ≥100,000 hours |
| 20. | Weight | 70Kg /sqm |
| 21. | IP rate | IP65 ( front side and rear side) |
| 22. | Average power consumption | 400W/sqm |
| 23. | Peak power consumption | 1300W/sqm |
| 24. | Input voltage | AC220V/50Hz ±10% or AC110V/60Hz ±10% or AC380V/60Hz ±10% |
| 25. | Operating Environment | Temperature:-20+60 Humidity:10%95%RH |
| 26. | Operating system | Windows 98/2000/ME/XP |
| 27. | Type of video signal |
S-video, composite video ,RGB ,VGA ,DVI |
