FHD Splicing Screen Commercial Wall Display , Video Wall LCD Monitors 450cd/M2

Brand Name	JB		Place of Origin	China
Model Number	JB/H38-LG

Delivery Time:3-10 working days after received your payment
Certification:CE/ROHS/FCC

55 Inch Lcd Did Video Wall With 1920*1080 Resolution 450cd/m2 With Hdmi Controller

Description:

55" LG video wall is one of Samsung most popular ultra narrow bezel lcd video wall panels. With 5.3mm

ultra narrow bezel, LED backlight and FHD 1080P resolution, it can be widly used in below fields:

Conference and meeting rooms, office building, lobbies, Security Monitoring Center, Surveillance and

Retail Center, Restaurant and hotel, Retail Shopping Mall Advertising and information Displays, Public

Installations, Exhibition and show center, Live show,Rental and advertising

Center,Museums,Church,Transportation and Mass Info Display systems.The splicing picture combination,

can reach the advertising media to the pursuit of large screen . Widly use to Airport, Finacial

,Metro,shopping mall,supermarket,Public.

Features :

? Use industrial-grade professional DID LCD splicing screen, designed for industrial monitoring and multimedia information display to achieve signal splicing display and achieve signal split display, windowing, superimposing, cross screen, zooming and other special displays. ? ? Ultra-narrow border design, bilateral seam up to 5.5mm. ? ? Support 7×24 hours, 365 days of continuous power-on, high reliability and stability, ? backlight life up to 60,000 hours. ? ? The system can meet both analog signal access and digital HD signal access, and various types of signal input can achieve single-screen display, combined splicing display, and full-screen splicing display. ? ? All signals are connected to LCD splicing screen through matrix to achieve signal switching and free combination and splicing. ? ? All splicing units can display the same or different sources on a single screen. ? ? The video signals can be connected to all kinds of storage devices to facilitate future access and access to the LCD splicing screen for real-time display. ? ? The entire large screen display system includes splicing screen, various matrices and image splicing processor, which can be controlled and managed through Foretell large screen control software.

technological Parameters:

Model No.	JB/H53-LG
Panel Size	55"
Max resolution	1920X1080
Screen Size [inch/cm]	55 inch
Panel Technology	S-PVA TFT with direct white LED backlights
Aspect Ratio	16:9
Color	8Bit,16.7M
Visual Angle (H/V)	178°/178°
Response Time	<=10ms
Life(hrs)	>60,000(hrs)
Input and output	?
DVI	1
HDMI	1
D15-RGB Input(VGA)	1
RJ45	2
Composit video input(AV)	2(2xBNC)
Composit video input	2(2xBNC)
Split screen	Support picture in picture(PIP/POP/PAP)
Power supply	AC100V~240V
Maximum power consumption	230W
Standby comsuption	<=3W
Temperature	?
Working temperature	0℃~50℃
Working Humidity	20%~80%
Dimension	121.5*68.6cm

Installment Design:

Display Way:

Screen Design:
