Energy Saving Outdoor P10 LED Sign Display 10mm CE / ROHS Standard

FOB Price

US$ 4 - 5 / Kilogram

1 Kilogram(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	NFCase		Place of Origin	China
Model Number	AIA-1

Product Description

Delivery Time:3-5 days
Certification:CE,FCC,MSDS

?
Energy Saving Outdoor P10 LED Sign Display 10mm CE / ROHS Standard
?
Feature:

Easy and fast maintenance, single strip can be dismounting; Power box is made of aluminum, good heat dissipation and high waterproof level; Width and height can be added endlessly as for fixed installation; It can be largely applied for outdoor led wall advertising and huge building decoration. DIP lamps, high brightness; Refresh rate >960HZ,Gray scale >14Bit； Mask adopts the buckle design, better evenness, and can be used repeatedly;? The cabinet is customized with stretch aluminium design, and weights only 34.6kg per sqm;

?

?
Future series is the full color LED panels specially designed for outdoor fixed advertising applications; it obtains characteristics of ultra thin, fast assembling, ultra bright, and etc.

Model:	FU10S	FU15S	FU18S	FU30S	FU37S
Pixel Pitch (mm):	10.416	15	18.75	30	37.5
Physical Density (dot/m2):	9,216	4,444	2,844	1,111	711
LED Configuration:	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B
LED Type:	DIP346	DIP346	DIP346	DIP346	DIP346
Module Size (mm x mm):	1000*42	1000*30	18.75*1200	1200*30	1200*37.5
Module Resolution (PX x PX):	96*4	80*2	1*64	40*1	32*1
Module Power Consumption (W):	25	25	12	8	12
Drive Mode:	Constant Current Drive	Constant Current Drive	Constant Current Drive	Constant Current Drive	Constant Current Drive
Horizontal Viewing Angle (Deg):	110	110	110	110	110
Vertical Viewing Angle (Deg):	45	45	45	45	45
Brightness (cd/m2):	6,500	8,500	8,000	5,000	6,500
Grey Scale:	14bit	14bit	14bit	14bit	14bit
Refresh Rate (Hz):	＞960	＞4800	＞4800	＞4800	＞4800
Cabinet Resolution (PX x PX):	128*96	80*40	32*64	40*20	32*16
Cabinet Max Power Consumption (W):	500	400	400	200	350
Cabinet Average Power Consumption (W):	200	240	160	120	140
Cabinet Size (mm x mm):	1000*1000	1200*600	600*1200	1200*600	1200*600
Cabinet Weight (Kg):	30	18.5	17.5	14	15
Features:	Light-Proof	Transparency	Transparency	Transparency??	Transparency??
Cabinet Thickness (mm):	89	90.5	93.44	95.44	95.2
Cabinet Material:	Aluminum	Aluminum	Aluminum	Aluminum	Aluminum
Color (M):	>16.7	>16.7	>16.7	>16.7	>16.7
Input Voltage (V):	AC 85V~250V10%	AC 85V~250V10%	AC 85V~250V10%	AC 85V~250V10%	AC 85V~250V10%
Refresh Frame Frequency (Hz):	50/60	50/60	50/60	50/60	50/60
Protection Level:	IP65	IP65	IP65	IP65	IP65
Working Environment:	Outdoor	Outdoor	Outdoor	Outdoor	Outdoor
Working Temperature (℃):	\"-20°- +40°	\"-20°- +40°	\"-20°- +40°	\"-20°- +40°	\"-20°- +40°
Operation humidity (RH):	10%-90%	10%-90%	10%-90%	10%-90%	10%-90%
Certificates:	CE	CE	CE	CE	CE
