Adjustable CZ Roll Forming Machine With Manual Or Hydraulic Decoiler
- T/T L/C D/P D/A
- 7 days
You May Like
-
Pre-punching Z Shape Cold Roll Forming Machine With Changeable Feeding Width
-
Chain Transimission Purpline Cold Rolling Form Machine With Cr12 Mould Steel Cutting Blade
-
Traditional Mould Type Double Layer Roll Forming Machine Auto Working Mode
-
Hydraulic Metal Glazed Roof Tile Making Machine , Tile Forming Machine
-
Auto Swisss Electric Cabinet Purlin Frame Making Machine With CE / SGS / ISO
-
High Speed Mold Forging Frame Making Equipment For Electric Cabinet
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
Adjustable CZ Roll Forming Machine With Manual Or Hydraulic Decoiler
?
?
1. Components of C Z Purlin Roll Forming Machine?
?
The roll forming machine includes 4tons manual uncoiler unit, sheet guiding equipment, straightening device, pre-punching device, roll forming system, cutting equipment, hydraulic station, electric controlling system(PLC) and run out supporting table.?
?
2. Technical Parameters
?
Material specification | galvalume, galvanized steel and carbon steel. |
Thickness | 1.0mm to 2.5mm. |
Main motor power | 15 kw. |
Hydraulic station power | 5.5?kw. |
Feeding width | changeable. |
Cover width | changeable. |
Yield stress | 235Mpa(33KSI) ~ 345Mpa (50KSI). |
Roll forming Speed | 12 m/minute. |
Cutting Tolerance | 2.5mm(length≤5000mm); 3.0mm(5000mm<length≤10000mm). |
Manual Uncoiler | Max. Capacity: 3000kgs. |
Coil inner diameter | 508mm. |
Voltage | As per customer’s request. |
Numbers of stands | 17?stands/stations/pairs. |
Type of cutting | Roll-formed and length-set profile cutting. |
?
3.?Material of Main Equipment??
?
Roller Material | GCr15 bearing steel, with quenching treatment. |
Active Shaft Material | High grade No.45 carbon wrought steel,which can improve the integrated mechanic feature of the shaft. |
Electric Elements | PLC control panel, transducer imported from Mitsubishi of Japan. |
Cutter blades | Cr12 mould steel with quenched treatment. |
?
4. Process sketch?
?
Uncoiling the sheet ---?Infeed guiding --- Straightening --- Pre-punching --- Roll forming --- Measure length?---?Cutting the panel --- Panels to the supporter (option: automatic stacker).
?
5. Specification
?
6. Series Design of Product??
?
?
Machinery?Show
?
?Photos right preserve.??
?
