9M Hydraulic Lift Platform 500Kg for Work Shop , industrial scissor lift

Brand Name	WORTHSUN		Place of Origin	China
Model Number	WS0.5-9

Delivery Time:20 days after order confirmed
Certification:CE ISO

9M Hydraulic Lift Platform 500Kg for Work Shop , ?industrial scissor lift

Main?Parameters

Loading Capacity???????? 500kg Maximum Height???????? 9000mm Minimum Height?????????? 1650mm Platform Size???????????????1900*1000mm Lifting Power??????????????? 2.2kw Motorized Power:?????????0.75Kw Power Voltage????????????? DC24V Lifting Time????????????????? 80s Cylinder?????????????????????? Ф100 (2PCS) Gear Pump???????????????? ?6ml/r Total Weight??????????????? 1260kg Measurement????????????? 2200*1200*1650MM

Description:

Mobile Scissor lifts are also called as mobile elevated work platform; they are used to provide temporary access for contractors to high, inaccessible areas on a variety of job sites such as maintenance, construction work or emergency access by firefighters. They are designed to lift limited weights and capable of being fully operated by a single person. They are narrow enough to be used in industrial settings and can be driven through narrow aisles with ease.

The scissor structure enables reliable stability when the lifts rising up, the broad platform and the high loading capacity get the aerial working more efficient and more safely.

Main Features:

1. Pointing control of lifting up and down.

2. Manganese steel lifting arm in high strength with rectangle shape

3. Anti-skid floor in platform

4.?The control panels are available on the platforms and ground.

5. Fine grinding cylinder in good sealing performance

6. Neatly folding guardrails make it easy to maneuver through doorways, into elevators and throughout other height-restricted areas.

Safety Precaution:

1. The operation voltage on the platform is 24V

2. Emergency stop button on the platform and ground

3. Auxiliary platform lowering

4. Telescopic legs on the chassis

5. Hose burst valve safety

6. Rain-proof design electric cabinet

7. Fence on the platform

Configurations:

Electric system: Schneider contactor, button, CHNT electrical Hydraulic System: Hycman brand power pack ,NOK sealing Scissor Arm Support: Hi-strength Manganese steel rectangle tube Q345 B Platform Surface : Antiskid checkered plate Tire: ?600-9 Inflated tires High-pressure Oil Pip: Double wire hydraulic intensifier rubber hose : Battery: (DC12V,150AH)*4 with charger

Optional Configuration:

Hydraulic Power Pack: Italy brand: Hydrapp/ Swiss brand: Bucher Extension Platform Rubber Solid Tire Flame Proof Control Cabinet

Applications:

1. Site: Work Shop, Theatre, Hospital, Library, Restaurant, Hotel Exhibition Hall etc.

2. Aerial Working Purpose: machine maintenance, painting, cleaning etc.

Spare parts for your maintenance of the machine:

Item	Quantity
Fuse	3
\"O\" Rubber Seals Φ11	3
Wrench	1
Pressure Oiler	1
Cross Screwdriver	1
Straight Screwdrive	1
