Wheel Type Mobile Crushing Plant and Screening Station , Mine Crusher

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Lipu		Place of Origin	China
Model Number	YG0830E4060

Delivery Time:15-20 days
Certification:ISO9001:2008,CE,IQNet

Wheel Type Mobile Crushing and Screening Station

Brief Introduction :

Wheel Type Mobile Crushing and Screening Station is high-efficiency and modular equipment. It can

work by single machine, as well as combination of several machines to be a plant. It is widely used in

road and bridge construction, urban construction, building garbage disposal, mining, metallurgical,

energy and other departments for crushing and screening operations.

Performance features :

1. Flexible, convenient and versatile; It can save a lot of infrastructure and removal cost;

2. Reasonable compact space layout greatly reduces the occupied space of the equipment in the field;

3. Crushing materials in working site immediately and moving with the mining surface of raw materials

greatly reduce the material transportation cost

4. The equipment chassis is high and the turning radius is small make it easy to travel on ordinary road

and the rugged road;

5. It can use external power supply, as well as high reliability diesel generator;

6. The technology for crushing and screening equipment is mature, structure is compact and

performance is stable.

Technical Data:

Wheel Mobile Jaw?Crushing Station:

Model	YG0830E4060	YG0830E5075	YG9538E6090	YG1149E75110	YG1249E86110
Feeder Model	GZD0830	GZD0830	GZD9538	GZD1149	GZD1249
Crusher Model	PEV400×600	PEV500×750	PEV600×900	PEV750×1100	PEV860×1100
Iron Separator Model (optional)	RCYD(C)-5	RCYD(C)-6.5	RCYD(C)-8	RCYD(C)-10	RCYD(C)-12
Tyre Parameters	Double- axle	Double- axle	Double- axle	Triplex-axle	Triplex-axle
Belt Conveyor Model(mm)	B500×8.5m	B650×8.5m	B800×8.5m	B1000×10m	B1200×10m
Belt Conveyor Discharging height(mm)	3000	3000	3000	3200	3200
Side Belt Conveyor Model(optional)	B500×4m	B500×4m	B500×4m	B650×5m	B650×5m
Side Belt Conveyor Discharging height (mm)	2800	2800	2800	3100	3100
Generator Power(kW)(optional)	80	120	160	200	250
Transport length(mm)	9700	10500	11900	13100	14600
Transport Width(mm)	2550	2550	2550	2550	2550
Transport Height (mm)	3650	3800	4000	4300	4500
Operation Length(mm)	9700	10500	11900	13100	14600
Operation Width(mm)	2550	2550	2900	2950	3300
Operation Height(mm)
