Stainless Steel Paddle Blade Industrial Drying Equipment For Iron Ore Powder

Stainless Steel Paddle Blade Industrial Drying Equipment?For Iron Ore Powder

Equipment Introduction:

Stainless steel paddle blade industrial drying equipment is one kind of heat conduction based horizontal
mixing and drying equipment. The required amount of heat for this equipment is rely on the indirect?
heating of heat conduction, so the air is not required or only little air is required in the drying process to?
take the moisture away, which greatly reduce the heat waste being taken away by the air and the?
utilization of heat is improved, it’s one kind of energy saving dryer and suitable for drying particles,?
powder and paste material. Stainless steel paddle blade industrial drying equipment can prevent from
acid/alkali corrosion and iron contamination.?
?
Working Principle:

KJG hollow paddle blade industrial drying equipment is one kind of low-speed mixing type and?
continuous indirect heating equipment to conduct heat to dry (chill-down) materials by the hollow blade?
of sector structure. There are two pieces of parallel rotation axes of mounted staggered blades in the?
jacket structure cylinder of tis equipment, many pieces of hollow blade of sector structure mounted on?
each axis staggered by a certain interval, there are two kinds of blades (feeding shear plane and return
shear surface), the axes rotate at low speed. The hot medium enters into the hollow rotary axes and?
blades through the rotary joint installed at the end of the rotating axes, be dried after heating, which will?
be discharged out of dryer through the rotary joint. In addition, the hot medium will be led into the jacket?
structure. Materials will be fed constantly through the feeding end, and which will be stirred and mixed?
through blades, and materials will be dried through heat conduction between the blades and jacket?
structure at the same time, and materials will be discharged while it’s being heated. The retention time?
can be adjusted by changing the height of the overflow weir. The raw materials will be fed into the dryer
and will be conveyed the?discharge port to be discharged out through the hollow paddle blades. The?
materials will be stirred by the hollow paddle blades during the conveying process, meanwhile, which?
will be dried through evaporation by the simultaneous heating of the hollow paddle blades and jacket?
structure, with high thermal efficiency. The continuously variable transmission is adopted and connects?
with the gear box in this dryer, 5-20rpm, the?rotation speed can be adjusted according to material?
properties. The air is being exhausted from exhaust vent.
?
