21000rpm Electro Grinding CNC High Processing Precision Milling 10.5A 5.5KW 380V

21000rpm Electro Grinding CNC High Processing Precision Milling 10.5A 5.5KW 380V

International Buyer.pls Note:

A. we will specify low product value in the shipping invoice so that there maybe no import taxs or Just very little.
B. Import duties,taxes and other charge are not included in the item price or freight,These charges are buyer\'s responsibility.
C. please check with your country\'s customs office to determine what these additional costs will be prior to bidding/buying.

Competitive Advantage:

Product features:

the cooling effect of the spindle is better. The durable years of the Bearings gets more longer.

Low noise, little vibration, good stability, high processing precision
Constant power spindle with low rotating speed and high torque; Low rotating speed used for drilling and milling or rough machining; High rotating speed used for engraving and milling or fine machining. This product has wide application.
Infinitely variable speed transmission for frequency changer with wide speed range
Adopt the ceramic core Aerial plug, more safe and reliable
The front end of the bearing use the water-cooling equipment ,?

Specifications:

Spindle mode:NYM125-9-21Z/5.5

Rotating speed:9000-21000rpm ? ? ? ??
Spindle parametric: ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?Overall size(mm):
Frequency:900Hz ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? D:125
? ? ? ? ? ? ? ? D1:100
Power:5.5Kw ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? L:317
Voltage:380V ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? L1:38
Electric current:10.5A ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? L2:46
Connect mode:ER32
Cooling mode:water
Bearings mode:2*7009 ? 2*7005
Weight:24.5KG

Tool holder’s diameter:2-20mm(Factory standard: 2 fillings)
Taper hole of spindle runout:≤0.003mm
Mandrel runout:≤0.008mm
Lubricating mode: grease

Description:

It can be used in the numerically controlled production center.The Motor Spindle can additionally store the encoder and have the rigidity tapping function.?It adopts six-pole motor-driven system and the BT40 knife handle, could usually be used in the quick processing of different materials with 12000rpm.?GDL125 series Motor Spindle is the automatic tools changing (can store encoder) spindle designed by our company. The multichamber protective measure including double-layer sealing device and air sealing conformation can efficaciously provide liquid from getting in and keep Motor Spindle working for a long time. The GMN import bearings and engine oil are used to ensure high performance of the spindle. Tool changing structure is advanced so that the signal and tool changing movement could be reliable and stable.?

Applications:

Applicable scope: Engraving machine or Engraving and milling machine and Lock industry. It is mainly used for the circular carving This product is suitable for and drilling and milling of the hardware, glassworks and woodworks.
