Home > Products > Outdoor Full Color LED Display > Advertising moving message rental LED display wall mounted 7000cd / m2 1 / 4scanning
Advertising moving message rental LED display wall mounted 7000cd / m2 1 / 4scanning
USD $4 - $5
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
16W advertising Flexible LED Display P8.928 / HD Rental LED Panel Screens
-
SMD custom P4 Indoor LED Video Walls dust proof Digital Front IP20 1 / 16scan
-
P10 Programmable electronic Indoor LED Video Walls Asynchronous for meeting room
-
Full color Stage Rental LED Display for advertising black MBI5124 CE / FCC
-
3G indoor LED display board for advertising / commercial LED pixel display
-
6mm Digital Indoor LED Video Walls Fixed Installation for Waiting Hall IP20
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
Advertising moving message rental LED display wall mounted 7000cd / m2 1 / 4scanning
?
Feature and Advantage
1. ?Waterproof and dustproof: IP65 front, IP65back
2. ?Best viewing distance: 10-100m
?
3. ?White balance brightness: More than 8000CD/sqm
?
4. ?Horizontal viewing angle: 120degree
?
5. ?Working temperatue: -20degree-+80degree
?
6. ?MTBF: More than 10, 000hours
?
7. ?Life span: More than 100, 000hours
8. ?Average power consumption: 300W
Application and Market
?
?
1. ?Application
?
?
Wide applied in stadiums, advertisement, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
?
?
2. ?Market:
?
?
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, MID East, Eastern Asia, Western Europe
Our service
?
1. ?Your inquiry related to our products or price will be replied in 24hrs
?
?
2. ?OEM&ODM, any your customized lightings we can help you to design and put into product
?
?
3. ?Distributoership are offered for your unique design and some our current models
?
?
4. ?Protection of your sales area, ideas of design and all your private information
?
?
5. ?Top quality+Reasonable price+Responsible After Service=Successful & Win
Specification:
| Description | Technical parameter | |
| Unit module | Module size | 160*160mm |
| Pixel pitch | 10mm | |
| Pixel density | 10, 000dots/m2 | |
| Pixel configuration | 1R1G1B | |
| Led specification | Φ 3ellipse | |
| Pixel resolution | W: 16dots*H: 16dots | |
| Cabinet | Dimension | 960mm*960mm*150mm |
| Quantities of module | 36pcs | |
| Power supply | 6pcs | |
| Thermal discharge | Fan*2pcs | |
| Total weight | 50kg | |
| Best viewing distance | 10-100m | |
| Temperature | Storage: -35degree~+80degree | |
| Working: -35degree~+85degree | ||
| Thickness | 15cm can adjustable | |
| Remarks: cabinet size can changed, upon project need. | ||
| Power | Working voltage | AC220V/110V± 10% |
| Average power consumption | 300-400W | |
| Max. Power consumption | ≤ 1000W/sqm | |
| Current | ≤ 20mA(single LED) | |
| Control system | CPU | Pentium4 or above |
| Operating system | WIN98/2000/NT/XP | |
| Control method | Synchronization | |
| Main technical parameter | Driving device | 1/4scanning |
| Drive type | Constant Current driver IC | |
| Refresh frequency | ≥ 800Hz | |
| Grey scale/colors | 256 levels of each color(R/G/B)/16.7M color | |
| Brightness of white balance | More than 8000cd/sqm | |
| Brightness adjustment | 256 levels of each color(R/G/B)by software | |
| Operating ambient humidity | 10%--95% | |
| Video signal | PAL/NTSC | |
| Control system | DVI display card+full color controller card | |
| MTBF | ≥ 10, 000hours | |
| Life span | ≥ 100, 000hours | |
| Flatness | Tolerance of interpixel ≤ 0.3mm | |
| Tolerance of modules clearance≤ 0.6mm | ||
| Power switch | Automatic switch | |
| Display mode | 960x960 | |
| Software | LED media player |
Company Information
Shenzhen Comcreating Co.,Ltd is a professional manufacturer engaging in the research and development, production, sales and service of LED display system.
With the continuous and stable development in the past 8 years, Shenzhen Comcreating Co.,Ltd has showed strong competition in the market both in products quality and service.?50 sets of advanced equipments including latest automatic optic-electronic test system are furnished in product line.the output is more than15kk LED each month.
Our products are CE approved, ROHS compliant, C-TICK and FCC certificated. We had provided more than 3000 LED displa
