1x3 Single Mode Fiber Optic Coupler Splitter 1550nm Single Window

FOB Price

US$ 4 - 5 / Kilogram

1 Kilogram(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	NFCase		Place of Origin	China
Model Number	AIA-1

Product Description

Delivery Time:3-5 days
Certification:CE,FCC,MSDS

1x3 Single Mode Fiber Optic Coupler Splitter 1550nm Single Window
?
JC Opto-electronics’ s? fiber optic coupler splitters are used to split optical signals or to combine optical signals from two (or more) fibers into one fiber based on Fused Biconical Taper (FBT) technology. Our single mode & multi-mode optical fused fiber coupler splitter comes in a wide range of split ratios with single/double/three windows. Available with 250um, 900um or 3mm pigtails, and can be terminated with all types of connectors or installed in rack mount modules.

Features

Low?insertion?loss Low?polarization?dependent?loss?(PDL) Low?wavelength?dependence?loss Varieties?of?coupling?ratios?available High?quality,competitive?price Excellent?environmental?and?mechanical?stability High?directivity?and?return?loss Tested?to?Telecordia?GR-1221

Application

FTTH/FTTX?network Passive?optical?network CATV?networks LAN?&?WAN Optical?fiber?communication?system Optical?fiber?testing?equipment Data?communications WDM?Network?monitor?

?
1*3?&?3*3?Fiber Optic Fused?Coupler?Splitter
?

Type	SM?Single?Window?Fused?Coupler
Grade?	P?	S?	P?	S
Port?Configuration?	1?x?3?	3?x?3?
Excess?Loss?(Typ.)?(dB)?	0.15	0.3	0.2	0.4
Insertion?Loss?(Max.)?(dB)?(1:1:1)	5.6?	5.8?	6.0?	6.4?
Uniformity?(Max.)?(dB)?	0.8?	1.0?	1.0?	1.2?
PDL?(Max.)?(dB)?	0.15	0.2	0.15	0.2
Operating?Wavelength?(nm)?	980+10,?1310+10,?1550+10,?1585+10,
Fiber?Type?	SMF-28E?,?G652D,?G657A1?
Directivity?(dB)?	>50
Operating?Temperature?(°?C)?	-20~+70
Packing?Size(mm)	Steel?tube:?3.0x54mm??ABS:?80x60x12,?100x80x10?or?OEM

?
Ordering Information:

FBT-	A	B	C	D	E	F	G	H	I
	Port	Grade	Coupling?Ratio	Wavelength	Fiber?type	Pigtail?	Length	Packing?size	Connector
2=1X2	P=P	00=Equal	S1=1310	SM=SMF-28E	1=250UM	1=0.5m	R=3X35	NA=NONE
3=1X3	S=S	01=1:99	S2=1550	G6=G657A1	2=900UM	2=1.0m	S=3X40	FP=FC/UPC
4=1X4		02=2:98	S3=850	M5=MM50/125	3=2.0MM	3=1.5m	T=3X54	FA=FC/APC
5=2X2		03=3:97	S4=980	M6=MM62.5/125	4=3.0MM	4=2.0m	U=3X60	LP=LC/UPC
