Sell Cut To Length Line

Place of Origin	China

Model No.:JKC-1300
Product Origin:China
Brand Name:King Jime
Price Terms:FOB
Payment Terms:L/C
Certification:
Description:Specifications: 1) Models: KJC 2) Material width (mm): 1000/1250/1,300 / 1,600 / 2,000 3) Material thickness (mm): 0.6 - 6.0mm 4) Coil load (kg): 2,000 / 3,000 / 7,000 / 10,000kg 5) Coil inner diameter (mm): 508 6) Coil outer diameter (mm): 1,200 7) Speed (m/min): 15-20 8) Staightening precision 9) Coil expansion: hydraulic 10) Gauge precision: +/-1.0 11) Power motor (kW): 100 12) Coil car: optional 13) Air hold down arm: stander Feeding features by PLC program from Mitsubishi: 1) NC servo feeding: operating with computerize numerical control by PLC program from Mitsubishi made in Japan. The electrical parts from Yaskawa made in Japan including servo motor, driver, encoder and interface screen 2) High precision feeding: to meet the coming of hi-tech industry, controlled by computer closed circuit feedback system to keep precision degree within +/-0.03mm 3) Feeding function: input 20 sets of different feeding length, each group provides 999 times for punching or cutting to satisfy processing of special products 4) High efficiency release device, match with adjustment of signal from the cutter or press machine through cable wire 5) Setting of feeding length: directly input feeding length on the control plate, and then it can reach needed distance. Max. feed length is 9999.99mm Outer packing: Wooden cases
